Nickle (Ni) PVD sputtering on Aluminum Plate application
- 10 Set / Sets per Month
- Shanghai
- T/T
- electrostatic flocking machine
- powder coating lab test machine electrostatic powder experiment spray machine optiflex 2 type
- electrostatic powder coating machine experiment lab powder spray machine optiflex 2 type
- It is suitable for high pressure cascade of spray gun of various types of spray machine
- Zinc Ash Recovery Furnace zinc ash recovery machine Zinc Ash Separator zinc ash regeneration unit
- Electric adjustment multi - mode liquid crystal intelligent electrostatic powder spraying machine
Product Details
Condition: | New | Type: | Coating Production Line | Substrate: | Aluminum |
Coating: | Vacuum Coating | Place of Origin: | Shanghai, China | Brand Name: | vakia |
Model Number: | MSC1213 | Voltage: | 380V | Power(W): | 120KW |
Dimension(L*W*H): | 4x4x3m | Weight: | 4000kgs | Certification: | ISO9001:2008 |
Warranty: | 18 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Application: Ni/Ag/Cu films deposition by magnetron sputtering coating technology. To generate the film which up to 3 microns.
The PVD coating films has excellent corrosion resistant and good conductivity abilities.
Key Features:
High productivity, high quality
Reliable color effect
Special planetary turning function
Special planetary evaporation coating function
Touch Screen Controlled and PL
SPECIFICATIONS | ||||||||
MODEL | VAKIA-MSC1213 | |||||||
TECHNOLOGY | DC Unbalance Magnetron Sputtering Deposition | |||||||
MATERIAL | Stainless Steel (S304) | |||||||
CHAMBER SIZE | Φ1250*1350mm (H) | |||||||
CHAMBER TYPE | Cylinder, vertical, front and back opetion- 2 doors | |||||||
EVAPORTATION SYSTEM | Either Eight (8) 760mm or Six (6) 700mm planets with a total length of 1050mm ( approx.) | |||||||
DEPOSITION MATERIAL | Nickle, Silver, Copper, Chrome, Stainless Steel, Aluminum etc. | |||||||
DEPOSITION SOURCE | Cylinder or Plannar Sputtering Targets | |||||||
CONTROL | PLC(Programmable Logic Controller) + Touch Screen | |||||||
PUMP SYSTEM | Rotary Pistonr Vacuum Pump SV630BF | |||||||
Rotary Vane Vacuum Pump D60C | ||||||||
Roots Vacuum Pump WAU2001 | ||||||||
Turbo Molecular Pump MAG2000 | ||||||||
Pre-treatment | Ion Source Plasma cleaning | |||||||
SAFETY SYSTEM | Numerous safety interlocks to protect operators and equipment | |||||||
COOLING | Cold Water | |||||||
POWER ELECTRICAL | 480V/3 phases/60HZ ( USA compliant) 460V/3 phases/50HZ ( Asia compliant) 380V/3 phases/50HZ ( EU-CE compliant) |
Please contact us for more information.
