wood chipper hammer mill/wood chipper made in china/wood chipper pto
- 100 Set / Sets per Month
- Any port of China
- Credit Card PayPal
- energy saving and big promotion wood charcoal briquette making machine
- Multifunctional wood crusher machine /wood crusher / wood pallet crusher
- professional and hot sale wood crusher equipment
- hot sale and best quality drum wood chipper machine 0086136736858300
- Wood chipper for sawdust coconut shell/ logs/hardwood pieces for barbeque charcoal008613673685830 with CE
- wood shaving briquette making machine
Product Details
Condition: | New | Mill Granularity: | 10-30mm | Number of Cutter: | 4 |
Length of Cutter: | 420mm | Cutter Diameter: | 150*70*8 | Place of Origin: | Henan, China |
Brand Name: | TZ | Model Number: | TZ | Dimension(L*W*H): | 1200*500*800mm |
Weight: | 120kg | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
wood chipper made in china use export standards wooden case
Product Description
wood chipper hammer mill/wood chipper made in china/wood chipper pto
Contact:Cathy
Mobile/Whatsapp/Wechat:+86 13673629307
Skype:taizy2031
QQ:2419066501
Tel:0086-371-86660712
Fax:0086-371-86660713
Introduction
Our company produces the chipper disc chipper, wood chipper, miscellaneous wood chipper, wood chipper is the production of high quality wood a special wood chipper, widely used in papermaking, particle board factory, and high density fiberboard factory, stubble factory, biomass power plant, wood factory, and other industrial and manufacturer of production preparation section before the preferred equipment. The main cutting raw material is peeling after the trail wood, bamboo, slab materials and cutting time fuelwood excess material, etc.
Structure composition
Mainly by the stand, feed port, cutter, casing, chipping blade and electronic component, the machine can according to need to adjust the peel and cut blade, the production of different specifications and thickness of the chip.
The inside of the machine(made by cast steel , very durable and wearproof)
The blade of the machine(made by alloy steel , very durable and wear-resistant )
Advantage
1.high output, low energy consumption
2. wood chip high quality, cost-effective.
3.Chipper disc chipper compact structure, rational layout, easy installation,operation and maintenance convenience.
4.high productive capacity
5.wood chip length can be in within the prescribed scope of free adjustment
Paramaters
Model | Blades | Inlet size(mm) | Cutter diameter (mm) | Blade size(mm) | Capacity (t/h) | Spindle speed(r/min) | Power (kw) | Size(mm) | Weight (kg) |
TZMX420 | 3 | 150*150 | 420 | 150*70*8 | 0.6-1.5 | 600 | 7.5 | 1200*500*800 | 120 |
TZMX600 | 3 | 180*150 | 600 | 200*100*10 | 1.5-3 | 600 | 15 | 1500*570*1050 | 380 |
TZMX700 | 3 | 190*200 | 650 | 230*120*12 | 2-6 | 600 | 18.5 | 1500*680*1100 | 480 |
TZMX800 | 4 | 200*200 | 735 | 230*120*12 | 3-8 | 550 | 30 | 1850*730*1240 | 550 |
TZMX950 | 4 | 230*250 | 830 | 250*120*12 | 5-10 | 550 | 37 | 1900*820*1500 | 800 |
TZMX1150 | 4-6 | 300*330 | 1150 | 340*150*14 | 8-13 | 600 | 75 | 2560*1150*1800 | 2100 |
TZMX1410 | 4-6 | 400*400 | 1410 | 480*170*18 | 10-16 | 600 | 110 | 2900*1400*2350 | 2800 |
More pictures for you review
Our customer
Packing and shipping pictures
purchase process
contact me
Company Profile
1. Wood working machinery
wood chipper, wood cutter, wood debarker, cotton stalk cutter, straw crusher, bamboo crusher, sawdust machine, mushroom wood hammer mill, drum chipper, wood wool making machine, wood shaving machine, wood flake machine, shaving machine, wood wool, thicknesser, surfacer, compass plane, wood shavings, shavings, excelsior, wood wool, excelsior tissue paper, bamboo shaving, scobs, wood chips, Flakes, keyway planer, spokeshave, shearer, embossing calender, shartle machine, wood paring machine, wood shaving machine, wood flaking machine
2. Briquette press machine
charcoal briquette machine, sawdust briquette machine, iron metal briquette machine, mineral salt brick press forming machine, bio mass briquette machine, sawdust hay coco fiber baling machine, compress machine, pellet briquette press, ring die pellet machine,
3. Farm machinery hay baling machine
Hay cutter, crop cutter, ensilage cutter, forage cutter, chaff slicer, straw breaker, straw shredder, chaff cutter, chaff cutter knife, straw cutter with feeder, hand straw cutter, guillotine, wheaten chaff, guillotine knife grinder, hand shear cutting machine, knife folding machine, guillotine shears, guillotine-type cutting machine, guillotine bar shear, lawn mower, grass cutter, hay tedder, nut-cracker, gate shears, hay spreader, slotter, hay pelleter, grassland, motor mower with binder attachment, motor mower, combined tedder-and-side rake, chain-type side-rake for motormower, tedder, buckrake hay stacker, cutrake, green gathering and piling machine, fodder chopper, hand hay cutter, straw chopper, weed, pullrake, guillotine costotome, shredded fodder, grass hay press, swath turner, hay-loader, tonsil guillotine
4. Nut processing machinery
Peanut sheller, walnut sheller, cashewnut sheller, peanut peeler, cashewnut peeler, peanut butter machine, almond sheller and peeler, peanut roaster, cleaner, stoner, vegetable processing machine vegetable washing machine, vegetable cutter, onion peeler, garlic peeler, onion slicer, onion strip packing machine,
5. Fruit processing machine
Fruit peeler, fruit cutter, banana slicer, orange peeler, orange washing machine, orange juicer, juice screw extractor, juice seperator, homogenizer, Sterilization machine, filtering machine, packing machinery filling machine, shrinking packing machine, oil filling machine, pallet wrapper pencil machine, mosquito coil machine, chalk machine
6. Animal Feed machines
Mineral salt licking block brick press machine, floating fish feed pellet machine, animal feed briquette press, feed crusher and mixer, bird feed pelletizer, silage cutter.
"Quality, Price, Time and Service" is the tenet of our business.
"Credit, Reposal, Negotiation and Cooperation" is our standard.
"Solidity, Creation, Factuality and Dedication" is the spirit of our company.
Zhengzhou Taizy Trading Co., Ltd.
TEL: 0086-371 -86660712
FAX: 0086-371-86660713
ADD: No.1394 East Hanghai Road, Economic-technological development Area, Zhengzhou, Henan
