DZYL Dynamic balance valve resistance
- 5000 Piece / Pieces per Month
- tian jin new port
- T/T
Product Details
Standard or Nonstandard: | Standard | Structure: | Diaphragm | Pressure: | Medium Pressure |
Power: | Hydraulic | Material: | Other, Stainless steel or brass | Temperature of Media: | Medium Temperature |
Media: | Water | Port Size: | DN15-200 | Place of Origin: | Hebei, China |
Model Number: | DZYL | Brand Name: | JINKETONGLI |
Packaging Details
wooden box outside
Product Description
1, valve body: high quality gray cast iron;
2, anticorrosion plastic body;
3, spring: stainless steel;
4: Diaphragm: Epdm buried fiber
5, valve: brass;
6, design life: 10 years.
7. Dynamic pressure balance valve has three functions, self-reliance type flow valve function, automatic balancing valve function, self-reliance type differential pressure valve function.Pump respectively in three operation modes of different transformation.Flow must be on self-reliance type flow valve function, give priority to with heat source variable flow when using manual balancing valve function, users as the main traffic conversion ChengZiLi type differential pressure valve function, avoid heat supply network frequent replacement of valve, reduce the cost.
character
1. Double disc structure, unbalanced force is small, compact structure.
2. Automatic constant user pressure difference, absorb the network pressure fluctuations, support controlled system of autonomous regulation.
3. Control the catheter front installation block valves, have automatic eliminate congestion function.
4. Adopt mixed compression technology, stepless adjustment, pressure control general tuning range is big.
5. Differential pressure calibration precision, high precision of adjustment.
6. Adopting outside pressure structure, tear open outfit is convenient.
7. All copper valve, valve core.
specification | length(mm) | flow range( m³/h) | KVS | connection method |
DN15 | 100 | 0.1-1.5 | 3 | threaded connection |
DN20 | 100 | 0.1-1.5 | 4 | threaded connection |
DN25 | 110 | 0.2-2 | 6 | flange |
DN32 | 180 | 0.5-4 | 12 | flange |
DN40 | 200 | 1-6 | 18 | flange |
DN50 | 230 | 2-10 | 30 | flange |
DN65 | 290 | 3-15 | 50 | flange |
DN80 | 310 | 5-25 | 95 | flange |
DN100 | 350 | 10-35 | 110 | flange |
DN125 | 400 | 15-50 | 160 | flange |
DN200 | 600 | 40-160 | 530 | flange |
1.We have the product warranty period of ten years
2.General offer are not containing 17% of the value-added tax, does not contain freight logistics. The price, as reported to tax, including freight price please indicate.
3.If the product function to describe any questions please call Advisory 0317-8338351 (Mrs Tian), we will have professionals to answer your questions.
4.Any products you want,our professional term and research staff will satisfied all your request .All the products can be customied
Hebei Tongli automatic control valve manufacturing Co., Ltd. was founded in 1995, the headquarters is located in the "township of the casting" Botou city of Hebei Province, four battalion development zone. The company is a professional manufacturer engaged in the research, production, and sales, through development and innovation for 20 years, research, production and sales of professional committed to the heating valve.
The company covers an area of 58000 square meters, 510 employees including 280 engineering and technical personnel. The marketing team of 180 sales of the elite 90 people, the company has international advancedtesting equipment 30 sets, 400 sets of CNC machine tools, products structure, the heating valve products as the leading factor, provides a full range of HVAC system design and installation, debugging program.
The company has passed the certification of ISO9001:2000 quality system, the two time the license of special equipment, the people's Republic of China occupational health and safety management system certification,environmental management system certification.
Company Profile
Hebei Tongli Automatic Control Valve Manufacturing Co., Ltd. is a comprehensive enterprise integrating valve research, production and sale. In recent years, our company has been mainly engaged in the development and production of HVAC and water supply, drainage valves, digital locked balance valves, flow control valves, self-reliance type dynamic resistance differential pressure control valves, balance valves, electric 3-way regulating valves, electric two-way valves, regulating valves, temperature difference and temperature control valves.
Our feed water series includes remote-controlled floating ball valves, hydraulic level control valves, hydraulic slowly-closing silencing check valves, vacuum regulator valves and so on. Some products have obtained 12 national patents, and our products have been endorsed by the ministry of construction as the construction, design staff preferred products, and are successively chosen by the national key projects.
Our company has are capable of casting, processing, assembly and quality inspection. We employ a number of domestic and foreign well-known experts and professors as technical advisers, constantly improve the technological content of products and develop new products to make technology tangible.
