Factory Price Steel Rope Transmission Wall Plaster(skype:taizy2031)

Factory Price Steel Rope Transmission Wall Plaster(skype:taizy2031) photo-1
Factory Price Steel Rope Transmission Wall Plaster(skype:taizy2031) photo-2
Factory Price Steel Rope Transmission Wall Plaster(skype:taizy2031) photo-3
Factory Price Steel Rope Transmission Wall Plaster(skype:taizy2031) photo-4
Factory Price Steel Rope Transmission Wall Plaster(skype:taizy2031) photo-5
Factory Price Steel Rope Transmission Wall Plaster(skype:taizy2031) photo-6
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Automatic Grade:
Automatic
Power(W):
2.2kw
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Automatic Grade Automatic
Power(W) 2.2kw
Rendering Thickness 25 mm
Rendering Height 5 m
Place of Origin Henan, China
Brand Name TZ
Model Number TZ-1
Dimension(L*W*H) 1350*800*500mm
Weight 195KG
Certification CE
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

best quality  steel rope transmission wall plaster

(skype:taizy2031)



contacts

Mobile: 0086-13673685830
Phone No: 0086-371-86660712
Fax No: 0086-371-86660713
Skype: Taizy2031

Viber:13673685830
WhatsApp:13673685830
QQ:2415066501


1.Application of steel rope transmission wall plaster



Automatic rendering machine is one kind of automatic rendering machinery ideally suitable for the construction/building industry. It can spray cement,gypsum,mortar,etc

Required plastering thickness <2.5cm, height <5m all can use this machine.



2.Feature of steel rope transmission wall plaster

1. It can reach the very top of the roof.

2. Combine with the screw and conveying belt to achieve the vibrating compaction, no aglu, no crack.

3. Fast positioning.

4. Hydraulic lifting methods to improve the stability of the machine.

5. If the cable fall off, the machine will stop automatically.

6. Larger hopper, more materials can be loaded.



3.Main technical parameter



Model



TZ-80A

TZ-80B

TZ-100

TZ-120

Plastering Speed

500m2/8H



500m2/8H



750m2/8H



1000m2/8H





Plastering thickness



4-30mm



4-30mm



4-30mm



4-30mm



Plastering Height

3.5-5m



3.5-5m

3.5-5m

3.5-5m



Voltage



380/220v



380/220v



380/220v



380/220v





Power



2.2kw



0.75kw



2.2kw



2.2kw



Weight



180KG



110KG



140kg

140kg

Size



1350*800*500mm



900*650*500mm



1000*800*500mm



1200*800*500mm



Transmission

Steel wire rope

Steel wire rope

 Rack drive

 Rack drive



Unique design of safety

1.Before changing the plastering angle, the switch refuse to startup, then avoid the damage of scraping board.



2.If the motor reverse, it will cut the power automatically to protect the wire from mass. Commutate the switch is OK.



3.If it got stuck when descending, the machine can cut the power automatically to avoid wire sling clipping.



4.Long time exposure outside, the wire will become rough, so if it brokes, the machine will get stuck for abnormal descending speed.



5.All the machine accessories are from the most popular companies in the world.We can guarantee it must be a high quality,hihg efficiency,and strong technical one.



6.Although hydraulic oil looses, it will not down back for its front heavy.
