Multifunctional coconut/palm/vegetable/soybean oil press machine
ing principle of oil extraction machine The power comes from main motor being passed on to the shaft, and with the rotation
there the worm push the oil crops seeds forward continually.because of the space
between squeeze chamber and squeeze worm become more and more tighter,also with
higher density of the raw material ,therefore the pressure increasing gradually.
Meanwhile,due to the friction from oil particles movement surely much heating will
appears, so far the two basic factors had been complete for oil technicals,they damage
the cell tissue and resulting in crude oil flows to the mixing tank via oil plate for further
simple filter,in this way,the oil residue was segregate on the screen.And related to
the cake residual ,they arebeing pushed out from special designed discharge hole.
Features of sunflower oil extraction machine :
1.Fully automatic with 2 vacuum oil filters ,not only save labor about 60%
(one or two person are okay for operate one machinebut also remove
residue so as to ensure the pure oil quality and meet the standard of health guarantee.
2.Small land using---only 10-20 square meters is enough for production
3.Widely-used: it can be used to completely press more than 20 kinds of oil crops,
such as peanuts,sesame ,rapeseeds,soybean,sunflower seeds and flax and etc by
third levels for one time.
4.Cake residual oil rate---only 6%-7%. So the cake also can be used for animal feed.
5.Low investment, get more profit
6.machine surface is made of chrome plated stainless steel, in line with food hygiene standards
Model |
TZ-80 |
TZ-100 |
TZ-125 |
Diameter of worm shaft (mm) |
80 |
100 |
125 |
Heating ring power |
2kw |
3kw |
3.75kw |
Speed of worm shaft (r/min) |
35 |
37 |
34 |
Capacity (kg/h) |
80-120 |
150-230 |
300-350 |
Weight (kg) |
780 |
1100 |
15000 |
Dimension (L*W*H) (mm) |
1700X1100X1600 |
1900X1200X1600 |
2600X1300X2300 |
