Auto massage oil filling and capping machine
- 10 Set / Sets per Month
- Shanghai
- T/T Credit Card
- auotmatic chemical filling machine
- good price of auotmatic bleach filling machine
- High quality bleach filling machine pet bottle filling machine
- Automatic Flow Type Bleach Liquid Filling Machine
- Automatic Manufacture Corrosive Materials Bleach Filling Machine
- Manufacture bottle bleach filling machine
Product Details
Condition: | New | Application: | Beverage, Medical, Chemical, Other, Beverage, Medical, Chemical, Machinery & Hardware | Driven Type: | Pneumatic |
Automatic Grade: | Automatic | Voltage: | 220V 50HZ | Power: | 1500W |
Packaging Type: | Bottles | Packaging Material: | Wood | Place of Origin: | Shanghai, China |
Brand Name: | Npack Auto massage oil filling and capping machine | Model Number: | NP-MFC Auto massage oil filling and capping machine | Dimension(L*W*H): | 2200mm*1300mm*1600mm |
Weight: | 900Kg | Certification: | CE ISO9001 | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
Standard Export Wooden Case Auto massage oil filling and capping machine
Product Description
Specifications
1 Auto massage oil filling and capping machine2 Contact parts is 304SS
3 Anti-drop and Leakeage and Foam
4Easy Adjust
NP-MFC Auto massage oil filling and capping machine
Filling and Capping Machine adapt 316SS pump to fill different type of liquid ,syrup,lotion ,shampoo
Configuration and performance, features:
1.low cost filling and capping in one machin
2.not stable container best choice machine
3.Adopt injection pump to fill high precision, large range of adjusting dosage.
4.The pump system don’t absorb the medicament, good chemical stability, be able to resist high temperature and erosion.
5.Low level liquid receiver, convenient to clean.
6.Filling system has the function of shrinking, no drop leak.
7.Apply to fill various viscosity liquid.
8.Special manipulator and guiding device are equipped on it to ensure the spray cap reliably fitted on the opening of container.
9.Filling nozzle is diving bottom of bottle to fill and moving up slowly, avoid foaming.
Magnetic moment capping system, adjust degree of tightness freely.
Main performance Parameter:
1.Name: Filling and Capping Machine
2.Model:NP-MFC
3.Applied bottle range:20ml-1000ml
4.Filling Nozzle:6 and 4
5.Cap Type: Aluminum cap, Plastic cap and Ropp Cap
6.Filling speed: 2400bottle-3000bottle/h
7. Power Source: 220V,50HZ
8.Air pressure:0.6Map
9.Air Consumption:0.25m3/min
10.Dimension:2200mm*1300mm*1600mm
Factory Photo
it is a professional manufacturer and supplier of various types of liquid, powder, paste, granular packing machines since 2008.And in 2012, NPACK stepped into a new stage, and supply one stop packaging solution. And turn key projects for customers, now NPACK is one of the top brand in packaging machineries, and get a good Reputation in the fields of Chemicals &cosmetics, Pharmaceuticals and Food industry. In 2014, NPACK invested a new Plant for printing self adhesive labels( stickers labels in rolls) SHANGHAI RENYI PRINTING TECHNOLOGY CO.,LTD
Our Team
Our Catalogue
Our Clients
The sold machine will be guarantee in one year, in the guarantee year, any spare parts broken due to supplier’s quality issue, the spare parts will be supplied free for customer, customer need to pay the freight cost if the parcel weight more than 500gram.The easy wearing out spare parts are not in the warranty terms, such as O rings, belts which will be supplied with the machine for one year using.
1.We offer machines training system, the customer can choose training in our factory or in customer workshop.The normal trainig days are 3-5 days;
2. We offer operation manual to customer
3. We take a traning video, and machine operation video to customer
4.we offer remote control service, if customer do not know how to operate and use the machine, we will offer this service
We will dispatch engineers to carry out installation and debugging of the equipment in buyer's place if requested. The cost for International double ways air tickets, accommodations, food and transportations, medical shall be paid by Buyer for the engineers. Buyer shall fully cooperate with Supplier's engineer and make all the installation condition ready to work. such as: water, electricity, raw material etc.The normal debugging term is 3-7days, and the buyer should pay US$100/day per engineer.
Company Profile
Shanghai Zhiquan Automation Equipment Co., Ltd. is a professional manufacturer of various types of liquid, powder, paste, granular packing machines. Our main products: NPF series of filling machines, piston filling machines, overflow filling machines, gravity filling machines, weighing filling machines; NPC series of rotary capping machines, inline capping machines; NP series of powder, liquid, granular automatic packaging machines; and washing machines, ovens, unscramblers, aluminum foil sealing machines, inkjet printers, labeling machines, rotary tables, conveyor belts and other auxiliary equipment. Our machines are widely applied to daily-chemical, cosmetics, pesticides, oil, food, beverage, pharmaceutical and other industries.
We always adhere to the principles of "technological innovation" and "excellent quality." We focus on product R&D while ensuring technology leadership and innovative features. All products are made of components and materials which are purchased from Germany, the United States, Japan, and South Korea, for the processing and assembling of our engineers and workers. They are the crystallization of our wisdom and labor. We use ISO9001:2008 quality management system and 5S on-site management practices to ensure the compelling product quality and accurate and timely supply. Our professional after-sale service team is ready to provide fast and efficient help for customers at any time.
After years of development, we have accumulated rich experience in fluid packaging. Whether agent or cream, high-foam or corrosive products, we will provide you with the most reasonable solution in the first time. Excellent service and good reputation make us to be the leading supplier in this industry. Products have been exported to more than 50 countries and regions, including America, Europe, the Middle East, and Southeast Asia, being well received by our customers.
We will confirm to you by excellent quality and efficient after-sale service. Zhiquan IS YOUR BEST CHOICE.
