Chinese Chalk Piece Making Machine

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Dustless:

Yes

Color:

Color

Size:

660x500x350mm

Zhengzhou Taizy Trading Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

any port of China

Delivery Detail:

Delivery time depends on order quantity.

Dustless Yes

Color Color

Size 660x500x350mm

Packing wooden boxes

Brand Name TZ

Model Number TZ800-1

Place of Origin Henan, China

Chinese chalk piece making machine

Contact:Cathy
Mobile/Whatsapp/Wechat:+86 13673629307
Skype:taizy2031
QQ:2419066501
Tel:0086-371-86660712
Fax:0086-371-86660713

Details for the machine

1.Fill the water into the slaked lime mixer,the rate of slaked lime and water is half to half,but the slaked lime should be good quality.

2.The mould should be lubricated enough and lubricated every cycle,also need to be clean on time.

3.Each mould has 80 spaces for the filling,each cycle will take 6 minutes.

4.When the filling completed, turn over the mould, wet chalks come off the mould,and then dry them in the sun or dryer.

5.The packing should be completed by hand.

6.Final shape can be round,rectangle,or star shape.The length of the chalk can be 75mm-105mm.

Parameters

Model	Capacity	Weight	Volume
TZ800-1	6,000-8,000 pcs/h	70 kg	0.8 m3
TZ800-2	8,000-12,000 pcs/h	300 kg	1.65 m3
TZ800-4	12,000-24,000 pcs/h	400 kg	2.5 m3
TZ800-6	24,000-32,000 pcs/h	650 kg	3 m3
TZ800-8	35,000-48,000pcs/h	820 kg	3.5 m3
Remarks: the size of the chalk: the diameter of two heads are 10mm and 8mm. The length is 75mm.Or we can produce mold as your requirement.
