Hollow Pin Chain
Negotiable
MOQ: 100 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Type:
Other, hollow pin chains
Material:
Iron
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Big Pitch Conveyor ChainNegotiableMOQ: 100 Meters -
WH132 Welded Steel ChainNegotiableMOQ: 100 Meters
-
T200 Forging Scraper Chain With Bar AttachmentNegotiableMOQ: 100 Meters
-
T142 Forging Chain With Scraper AttachmentNegotiableMOQ: 100 Meters
-
P150-A1 Bottle Washing ChainsNegotiableMOQ: 100 Meters
Standard or Nonstandard
Standard
Type
Other, hollow pin chains
Material
Iron
Tensile Strength
standard
Place of Origin
Zhejiang, China
Brand Name
jiexiang
Model Number
all
hollow pin chain
All series hollow pin chains:
Materials: 40Mn steel or stainless steel
Color: netural,dark...
|
Chain No. |
Pitch |
Roller |
Width between inner plates |
Pin diameter |
Pin length |
Lnner plate depth |
Plate thick -ness |
Ultimate tensile strength |
Average tensile strength |
weight per meter |
||
| P | d1 max |
b1 min |
d2 max |
d3 max |
L max |
Lc max |
h2 max |
t/T max |
Q min |
Q0 |
q | |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | kN/LB | kN | kg/m | |
| C2042HP | 25.40 | 15.88 | 7.85 | 5.63 | 4.00 | 16.5 | 17.6 | 12.0 | 1.50 | 11.0/2500 | 12.6 | 0.78 |
| C2052HP | 31.75 | 19.05 | 9.53 | 7.22 | 5.12 | 20.5 | 21.8 | 15.0 | 2.03 | 20.0/4636 | 22.8 | 1.25 |
| C2062HP | 38.10 | 22.23 | 12.70 | 8.31 | 6.00 | 25.8 | 26.8 | 17.0 | 2.42 | 24.0/5455 | 27.1 | 1.72 |
| C2082HP | 50.80 | 28.58 | 15.75 | 11.40 | 8.05 | 32.4 | 33.8 | 24.0 | 3.25 | 50.0/11364 | 55.2 | 2.82 |
| C2052HPF1 | 31.75 | 19.05 | 9.40 | 7.03 | 5.12 | 20.0 | 21.5 | 15.3 | 1.85 | 15.0/3409 | 17.3 | 1.21 |
| C2042H-HP | 25.40 | 15.88 | 7.85 | 5.63 | 4.00 | 18.8 | 19.9 | 12.0 | 2.03 | 11.0/2500 | 13.2 | 0.95 |
| C2052H-HP | 31.75 | 19.05 | 9.53 | 7.22 | 5.12 | 22.1 | 23.4 | 15.0 | 2.42 | 20.4/4545 | 23.5 | 1.44 |
| C2062H-HP | 38.10 | 22.23 | 12.70 | 8.31 | 6.00 | 29.2 | 30.2 | 17.0 | 3.25 | 24.0/5455 | 27.6 | 1.99 |
| C2082H-HP | 50.80 | 28.58 | 15.75 | 11.40 | 8.05 | 36.2 | 37.6 | 24.0 | 4.00 | 50.0/11364 | 56.5 | 3.26 |
| HP40 | 40.00 | 22.00 | 8.75 | 9.00 | 6.00 | 23.0 | 24.2 | 18.0 | 2.50 | 20.0/4545 | 21.0 | 1.49 |
| HP50 | 50.00 | 31.00 | 14.50 | 13.20 | 10.40 | 31.1 | 32.5 | 25.0 | 3.10 | 30.0/6818 | 34.2 | 3.29 |
| HP50F4 | 50.00 | 31.00 | 15.00 | 13.20 | 10.20 | 36.5 | 38.0 | 25.0 | 4.00 | 40.0/9091 | 44.8 | 3.73 |
| 63HPF1 | 63.00 | 40.00 | 15.00 | 16.00 | 12.10 | 35.0 | 36.2 | 28.5 | 4.00 | 50.0/11364 | 56.7 | 4.20 |
| 4202HP | 50.80 | 31.80 | 15.00 | 14.00 | 10.10 | 36.3 | 39.0 | 26.0 | 3.80 | 42.0/9545 | 21.6 | 3.75 |
| 4203HP | 76.20 | 31.80 | 15.00 | 14.00 | 10.10 | 36.3 | 39.0 | 26.0 | 3.80 | 42.0/9545 | 47.1 | 3.01 |
| 42035HP | 88.90 | 31.80 | 15.00 | 14.00 | 10.10 | 36.3 | 39.0 | 26.0 | 3.80 | 42.0/9545 | 51.1 | 2.79 |
| 4204HP | 101.60 | 31.80 | 15.00 | 14.00 | 10.10 | 36.3 | 39.0 | 26.0 | 3.80 | 42.0/9545 | 51.6 | 2.63 |
| 8403HP | 76.20 | 47.60 | 19.00 | 19.05 | 13.60 | 43.8 | 46.3 | 39.0 | 5.1/3.8 | 84.3/19159 | 130.3 | 6.81 |
| 8404HP | 101.60 | 47.60 | 19.00 | 19.05 | 13.60 | 43.8 | 46.3 | 39.0 | 5.1/3.8 | 84.3/19159 | 130.3 | 5.78 |
| 8406HP | 152.40 | 47.60 | 19.00 | 19.05 | 13.60 | 43.8 | 46.3 | 39.0 | 5.1/3.8 | 84.0/19091 | 130.3 | 5.18 |
| HP75 | 75.00 | 40.00 | 22.00 | 18.00 | 12.20 | 42.0 | 44.0 | 35.0 | 4.0 | 60.0/13636 | 72.0 | 5.57 |
| HB76.2 | 76.20 | 31.75 | 15.50 | 12.70 | 9.50 | 35.5 | 37.0 | 26.0 | 4.0 | 42.0/9545 | 49.2 | 3.25 |
| HP80 | 80.00 | 50.00 | 20.00 | 24.00 | 18.50 | 44.5 | 46.1 | 40.0 | 5.0/4.0 | 79.0/17953 | 92.5 | 6.81 |
| HP100 | 100.00 | 45.00 | 22.00 | 16.00 | 12.00 | 46.0 | 47.5 | 35.0 | 5.0 | 75.0/17044 | 90.0 | 6.20 |
| HP100F1 | 100.00 | 45.00 | 22.00 | 18.00 | 12.00 | 47.2 | 48.5 | 35.0 | 5.0 | 75.0/17044 | 90.0 | 6.15 |
