Schenck Balancing Machine for Turbochargers HM4-20B/TL

Name: Schenck Balancing Machine for Turbochargers HM4-20B/TL
Brand: Schenck
SKU: 122668471

US$ 100,000 - 1,500,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

Schenck

Model Number:

HM4-20B/TL

Schenck Shanghai Machinery Corp., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name Schenck

Model Number HM4-20B/TL

Power Electronic

Usage Vibration Testing Machine

Specifications

specially balancing machine for turbochargers
Hard Bearing Balancing Machine
schenck
turbochargers balancing

Schenck balancing machine for turbochargers , HM4-20B/TL

specially for turbochargers and other rotors

With bearing pedestal HM4BU and HM20
Cast iron machine construction with roller chain for moving the bearing pedestals
Apply for all kinds of turbocharger rotors
All rotors can be balanced according to the balancing instructions of the manufacturer
Electro-dynamic vibration force pickup, highly measuring precision
Under-slung belt drive

Product Specification of this Balancing machine
This machine is designed for balancing all kinds of turbocharger rotors and other rotors such as armature, motor, flywheel according to demanding of our customers. Its specialty that there are two bearing pedestals selection under belt drive and mostly satisfied variety rotors

Product parameters of this Balancing machine

Important data at a glance		HM4-20B/TL
Bearing pedestal		HM4	HM20
Rotor weight	kg	1500	Max.120
Per bearing pedestal	kg	Max. 750	60
Distance between bearing centers with belt drive	mm	Min. 160	Min. 85
Rotor swing diameter above the machine base	mm	Max. 1600	Max. 800
Journal bearing diameter	mm	Max. 100	Max. 70
Journal bearing diameter	mm	Min. 12	Min. 9
Rotor data 1)	mm	Min. unlimited Max. 2750
Drive data
Belt driving diameter	mm	20-600
Balancing speeds based upon 100mm belt driving diameter approx. 2)	rpm	140-1400 200-2000 350-3500
