5W RGB Cartoon Laser Light With Analog Modulation

Name: 5W RGB Cartoon Laser Light With Analog Modulation
Brand: Colorful Star
SKU: 122655177

US$ 4,000 - 4,300 MOQ: 1 Piece

Key Specifications

Input Voltage(V):

110V/220V

Lamp Power(W):

150

Working Temperature(℃):

-20, 45

Guangzhou Colorful Star Stage Lighting Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou/Huangpu/Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Input Voltage(V) 110V/220V

Lamp Power(W) 150

Working Temperature(℃) -20, 45

Working Lifetime(Hour) 10000

Certification CE, EMC, LVD, UL

Emitting Color Other, RGB full colors

Place of Origin Guangdong, China

Brand Name Colorful Star

Model Number LS510-RGB5000

Specifications

1 Big power & full colors laser light
2 Analog modulation or TTL 0~20K
3 0~35Kpps for scanner system
4 For big stage show

RGB5000 Analog Modulation Cartoon Laser Professional Lighting
Item name	5W RGB cartoon laser light with Analog modulation
Item No	LS510-RGB5000
Voltage	AC110V/230V 50~60Hz±10%
Power consumption	150w
Laser source	Solid semi-conductor laser generator
Modulating signal	Analog modulation or TTL 0~20K
Laser wavelength	532nm & 650nm &447nm
Laser power	5000mW(G1000mW/532nm+R1000mW/650nm2+B1000mW/447nm2) We all use China CNI laser !!!
Color	Full colors
Scanner system	30~35Kpps (you can use Pangolin to test the scanner speed)
Scanner angle	±20 degree
Control signal	DMX-512 international standard signal
Control channel	12
Control mode	DMX-512, music control, automatic,master&slave,ILDA control
Operating environment	Indoor
Working temperature	-20°C~45°C

DMX-512

Channels		DMX512	Control
CH1	Close laser and Laser control	0~41	Close laser
		42~83	AUTO, ch2~ch10 control
		84~167	AUTO,ch2~ch10 can’t work
		168~251	Music control, ch2~ch10 can’t work
		252~255	Music control, ch2~ch10 control
CH2	Choose the patterns	42~83	Choose the patterns
CH3	Rotate the angle and speed	0~255	Rotate the angle and speed
CH4	Zip and roll from left to right	0~255	Zip and roll from left to right
CH5	Zip and roll from up and down	0~255	Zip and roll from up and down
CH6	Move the patterns control	0~255	Move from up and down,
CH7	Move the patterns control	0~255	Move from left to right
CH8	Zoom the patterns	0~255	Zoom the patterns
CH9	Graduallyb draw the patterns	0~255	Gradually draw the patterns speed
CH10	Scan speed choose	0~255	Scan speed choose
CH11	Colors setting	0~255	Choose the colors and change colors
CH12	Colors change speed	0~255	Change colors’ speed
