Specifications
Alarm Car System with SMS/GPRS/GPS tracking1.Small size,easy installation
2.Wide voltage:9-36V
3.Device consumption<60mA
Alarm Car System with SMS/GPRS/GPS tracking
main functions:
1. Locating and Tracking.Information, such as speed, location, moving direction and elevation above sea-level of vehicle, can be tracked by monitoring center anytime.
2. Over-speed Alarm.If the speed of vehicle is over the preset speed, GPS terminal will warn the driver and send over-speed alarm to monitoring centre.
3. Emergency Alarm.If the vehicle is hijacked and backfired, the driver can positively give an alarm to monitoring centre
4. Cut-off of Oil and Electricity.Safely cut-off oil and electrical supply of vehicle in long-range.
5. Alarm of Crossing Border.AS the vehicle runs into or out of the specific area, the monitoring center will accept alarm at once.
6. Playback of Track.Make query of historical tracks of vehicle.
Characteristics of automobile GPS terminal (advantages):
l Small size: Difficult to find and easy to install,
l Low power consumption: Nearly have no infection to the vehicle battery.
l Excellent Stability: Industrial grade of chip, professional anti-interference process, multilevel battery protection and reliable equipment operation
Characteristics of monitoring center:
l Excellent interface and convenient operation,
l Efficient dispatching system and support of more online vehicle,
l Two version of software(C/S and B/S version), especially B/S version of software is very convenient for customer to examine vehicle and check historical track.
l Software interface of monitoring and control centre can be customized according to customers requirement and habit of usage.
Technical Parameters
GSM module:850/900/1,800/1,900Mhz (optional) or GPRS/CDMA TCP/UDP
GPS module: U-BLOX 5-generation module (other module is considered)
GPS sensitivity:160dbm
GPS frequency: L1, 1,575.42 MHz
Channel: 16-channel checking and tracking
Position precision: Less than 10m
Time precision: Global synchronous GPS time
Cold start:45s
Warm start: 38s
Hot start: Less than 5s
Speed limit: Max 515m/s (1,000knots)
Acceleration limit: Less than 4g
Working temperature :-40 +85
Storage temperature :-20 +70
Dimension: 65mm(L) 45mm(W) 25mm(H)
Working voltage:9V-36V
Working current:80mA@DC12V
Company certificate:
