Help Center5*0.5mm(Width*Thickness) Stepless Ear Hose Clamps
Related Products
-
9*0.8mm(Width*Thickness) Stepless Ear Hose ClampsNegotiableMOQ: 2000 Pieces -
One Ear Hose Clamps With Mechanical InterlockNegotiableMOQ: 5000 Pieces
-
7*0.6mm(Width*Thickness) Stepless Ear Hose ClampsNegotiableMOQ: 5000 Pieces
-
10*1.0mm(Width*Thickness) Stepless Ear Hose ClampsNegotiableMOQ: 500 Pieces
-
PEX Series Stepless Ear Hose ClampsNegotiableMOQ: 5000 Pieces
Specifications
Stepless Ear Hose Clamps,with narrow band,stepness over 360degree,clamp ear,dimple & special formed strip edges.Features
1. Narrow Band: concentrates transmission of clamping force, less weight
2. Stepless over 360°: uniform compression or uniform surface pressure
3. Clamp ear: compensates for component tolerance, adjustable surface pressure
4. Dimple: increases clamping force, spring- effect compensates for changes in diameter due to thermal expansion
5. Specially formed strip edges: reduced risk of damage to parts being clamped
Material: 304 Stainless Steel
Band Dimension(W*T): 5 x 0.5mm Customer- specific sizes available on request
Item |
D |
Range (Closed-Open) |
Closing Force |
Carton Quantity |
||
mm |
inch |
mm |
inch |
N |
pcs |
|
S5065 |
6.5 |
.256 |
5.3-6.5 |
.209-.256 |
1000 |
20,000 |
S5070 |
7.0 |
.276 |
5.8-7.0 |
.228-.276 |
1000 |
20,000 |
S5075 |
7.5 |
.295 |
6.3-7.5 |
.248-.295 |
1000 |
20,000 |
S5080 |
8.0 |
.315 |
6.8-8.0 |
.268-.315 |
1000 |
20,000 |
S5087 |
8.7 |
.343 |
7.0-8.7 |
.276-.343 |
1000 |
20,000 |
S5090 |
9.0 |
.354 |
7.3-9.0 |
.287-.354 |
1000 |
20,000 |
S5095 |
9.5 |
.374 |
7.8-9.5 |
.307-.374 |
1000 |
20,000 |
S5100 |
10.0 |
.394 |
8.3-10.0 |
.327-.394 |
1000 |
10,000 |
S5105 |
10.5 |
.413 |
8.8-10.5 |
.346-.413 |
1000 |
10,000 |
S5109 |
10.9 |
.429 |
9.2-10.9 |
.362-.429 |
1000 |
10,000 |
S5113 |
11.3 |
.445 |
9.6-11.3 |
.378-.445 |
1000 |
10,000 |
S5118 |
11.8 |
.465 |
10.1-11.8 |
.398-.465 |
1000 |
10,000 |
