Bridge slab marble cutting machine
| Product Type | XZQQ625 |
| Blade Diameter | 350-625mm |
| Max.Working Dimensions(L×W×H) | 3200×2000×180(mm) |
| Workbench dimension | 3200×2000mm |
| Workbench tilting degree | 0°-85° |
| Workbench rotating degree | 0°-90°/45° |
| Blade Tiltable Degree | 0°-45° |
| Power of main motor | 15kw |
| Water consumption | 3.5m³/h |
| Weight | 6500kg |
| Overall Dimension | 6000×4800×2800(mm) |
The machine is controlled by microcomputer.The blade can maximally rotate 45 degrees.The workbench is rotatable for 360 degrees, which can be turned to 45 degrees at one time.And the workbench can maximally rotate 85 degrees in vertical.Precise assembly ,special protector for side beams and touching operating system make it high accurate,high stable,high efficent and easy operating.Thus the machine is quite good for large granit and marble stone's cutting and processing.
1.We promise one year warranty.
2.If you requires we will arrange installation person to install the machine and teach how to operate it.
XINGYI POLISHING MACHINE CO.,LTD.
Address: NO.C2,Area 11,Anping Development Area,Quanzhou City,Fujian Province,china.
Tel: +86-595-36792992
Web: www.xymachinery.en.china.cn
Supplier Martin Tsai
If you want more details or have any questions,we do appreciate for receiving your message.
Skype: xymachinery02
Send Inquiry to This Supplier
