Diameter Rubber Hose

Diameter Rubber Hose thumbnail-1
Diameter Rubber Hose thumbnail-2
Diameter Rubber Hose thumbnail-3
Diameter Rubber Hose thumbnail-4
Diameter Rubber Hose thumbnail-5
Diameter Rubber Hose thumbnail-6
Diameter Rubber Hose photo-1
Diameter Rubber Hose photo-2
Diameter Rubber Hose photo-3
Diameter Rubber Hose photo-4
Diameter Rubber Hose photo-5
Diameter Rubber Hose photo-6
US$ 0.58 - 1.28 MOQ: 1000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
Qinlong
Model Number:
6,8,10,13,16,20,25,30bar
Contact Supplier Request Quote Chat Now
Baoji Qinlong Fire Hose Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shaanxi, China
Brand Name Qinlong
Model Number 6,8,10,13,16,20,25,30bar

supply fire fighting equipments -fire  hose with couplings

1.  warp: polyester yarn.

     weft: polyester filament

2. weaving :  plain/twill

3.   lining: natural rubber,PVC,TPU/PU

4.  features :

    1) high pressure .resistance

    2) anti-wear,aging

    3) non-permeable

    4) incurvation resistance

    5) flexble and pliable

5. applications: fire fighting car,extinguishing fire,high offical building ,mining, water  transporation, agriculture

diameter rubber hosediameter rubber hosediameter rubber hosediameter rubber hosediameter rubber hose
 6. Technical Parameters



 Model

          Diameter

Working Pressure

   (MPa/Bar/Psi)

Test Pressure  (MPa/Bar/Psi)

Burst  Pressure

(MPa/Bar/Psi)



Length

Inner Dia (inch)

Inner Dia (mm)



C 8



    1.5

    40





   0.8 / 8/120





1.6/16//240





2.4/24/360





10m-50m

     2

    50

    2.5

    65

    3.2

    80

     4

    100



C 10



    1.5

    40





1 / 10/150





2/20//300





3/30/450





10m-50m

     2

    50

    2.5

    65

    3.2

    80

     4

    100



C 13



     1

    25





   1.3/ 13/190





2.6/26//380





3.9/39/570





10m-50m

    1.5

    40

     2

    50

    2.5

    65

    3.2

    80

     4

    100



C 16



     2

    50



1.6 / 16/240



3.2/32/480



4.8/48/720



10m-50m

    2.5

    65

    3.2

    80



C 20

     2

    50



2 /20/300



4/40/600



6/60/900



10m-50m

    2.5

    65

    3.2

    80
