Led tube Lamp bracket t5 t8 integrated batten fixture
We recommend our new model thickness 0.4mm, 0.7mm fixture. We can make the wiring as your requirements.
Item Name: |
Songly T5/T8 Fixture / Intergrated Batten |
||
Lamp length |
Dimensions (L*W*H) |
Material |
Thickness |
60cm-single |
630*40*58mm |
Iron/Aluminum |
0.2-0.5mm |
60cm-double |
630*80*65mm |
Iron/Aluminum |
0.2-0.5mm |
120cm-single |
1230*40*58mm |
Iron/Aluminum |
0.2-0.5mm |
120cm-double |
1230*80*65mm |
Iron/Aluminum |
0.2-0.5mm |
|
New mould -120cm 0.4mm-single |
1225*32*50mm |
Aluminum |
0.4mm |
|
New mould -120cm 0.7mm-single |
1225*33*51mm |
Aluminum |
0.7mm |
Led tube Light Fixtures Power:
Fluorescent lighting T8 fixtures: Fluorescent lighting T5 fixtures:
1*18W,1*30W,1*36W,1*54W 1*14W,1*28W,1*35W
2*18W,2*30W,2*36W,2*54W 2*14W,2*28W,2*35W
3*36W,3*54W
Two type holder (Black / Green) can be choosed.
1.Features:
The Fixtures Structure:
Housing-- made of advance material:Iron ,Aluminum
The Diffuser Cover thickness-- 0.2mm-0.5mm
End Caps-- White ABS material
2.The surface:
White powder coated,protects against rust and Anti-corrosion plastic finished
3.Lamp source:
Traditional T5 T8 tube with CE,RoHS,EMC,LVD certification
Led T5 T8 lighting tube with CE,RoHS,EMC,LVD certification
Self ballasted t5 in t8 energy saving tube with CE,RoHS,EMC,LVD certification .
4.About ballast:
1. Without ballast or starter, save the cost of maintenance,only for LEDT5,LEDT8.
2.With High efficiency electronic ballast / magnetic ballast,capacitor starter.
5.The lamp holder:
produced with high-grade flame retardant materials, so it can be safer.
6.The lines structure: more scientific,adopt the embedded lighting fixtures.
7.Voltage: 220V-240V50HZ or 90V-110V 50/60HZ
8.Fixtures Inside:with terminal block for main power connection
Different model as fllowing :
1.standard export packing:Foam+box+pallet
2.Every with one plastic bag.
3.Different model different package:
Single light fixture: 50pcs/carton
Double light fixture:25pcs/carton
Neutral packing, Hard kraft paper box packaging, particularly heavy or large product sourcing wooden reinforcement.
Q1. Are you a manufacturer or a trading company?
We are a manufacturer,providing OEM & ODM service.
Q2. What is the delivery date for a sample?
Usually about 2-3 days for items with general requirements.
Q3. Are your products conforming to our standards?
Yes, our products pass the testings as you require,e.g:CE, RoHS,FCC, SAA,PSE,etc.
Q4. How do you control the quality ?
We control the product quality by IQC,three tests on production lines,and 100% aging testing before packaging.
Q5. What's MOQ?
MOQ is depend on different items and models. Of course,we could accept small trial orders for certain items.
Q6. Can you give us a favorable discount ?
Of course, a favorable discount will be offered if the quantity is sizable.
Q7. How do you ship the goods and how long does it take?
We usually ship by DHL,UPS,FEDEX,TNT. It usually takes 4-5 days to arrive.By air,by sea are also acceptable.
