Home > Products > Embedded Industrial Control Computer > Intel Core i7-2710QE 2.1GHz Intel Core i5-2510E 2.5GHz 1*DVI 2*LAN 6*USB 2*COM fanless mini pc
Intel Core i7-2710QE 2.1GHz Intel Core i5-2510E 2.5GHz 1*DVI 2*LAN 6*USB 2*COM fanless mini pc
- 500 Set / Sets per Month
- Qingdao port
- T/T
Product Details
Products Status: | Stock | Type: | Embedded Computer | Brand Name: | FSX |
Model Number: | FSX-QM670 | Place of Origin: | Shandong, China |
Product Description
Product Overview
The product is a based on Intel® QM67 Chipset design, high-performance, highly reliable, fanless industrial-grade embedded multifunction miniature cassette machine. It can provide customers with flexible product feature set and performance requirements.
CPU | Intel® Core™ i7-2710QE 2.1GHz CPU/ Intel® Core™ i5-2510E 2.5GHz CPU | |
Chipset | Intel® QM67 | |
RAM | DDR3 SODIMM ,Maximum support 8G | |
Display interface | VGA | DB-15 x 1,Maximum 512MB shared system memory |
DVI | DVI-I x1 (DVI – D digital signal) | |
Storage device | Interface | 2*SATA |
HDD | 1*2.5″SATA | |
| MiniCard | 1, support half/full length size, mSATA(Optional) |
USB | 6 | |
Network | Networking chip | 1000M Ethernet *3, Intel® 82577LM/82574L |
Ethernet port | RJ-45*2 | |
Front I/O | USB | 2 |
| Audio | HD Audio, support Mic-in, Line-in and Line-out |
| Other | power button |
Rear I/O | USB | 4 |
Ethernet port | RJ-45*2 | |
serial port | 2 COM(1*RS-232,1*RS-422/RS-485) | |
| VGA | DB-15 x 1,Maximum 512MB shared system memory |
DVI | DVI-I x1 (DVI – D digital signal) | |
HDMI | HDMI x 1 | |
Power supply | DC_IN 12V-19V | |
Indicator light | front | POW*1,HDD*1 |
Power supply mode | DC_IN 12V,9~30V (optional) | |
Installation | Support wall hanging, embedded installation | |
Work temperature | -10-60℃(Require wide temperature hard disk) | |
Storage temperature | -40℃-80℃ | |
Storage humidity | 5%-95%,no condensation | |
Watchdog | Watchdog timer 256 ,Programmable time to interrupt, time to event reset | |
Anti-Vibration | 5g rms/5-500Hz/operation state-MinpcieDOM | |
1g rms/5-500Hz/operation state-HDD | ||
Impact resistance | 50G peak acceleration(duration 11 msec.)-MinpcieDOM | |
Total weight | 3.5KG | |
Dimensions | 250x220x60mm(WxDxH) |
Product Size
Product application industries
Order information
FSX-QM670:Intel® Core™ i7-2710QE 2.1GHz CPU/ Intel® Core ™ i5-2510E 2.5GHz CPU/1*HDMI/1*DVI/2LAN/6USB/2COM
paper carton ocean transport
1 years tecnical service
Qingdao Fu shun Xing Electronics Technology Co., Ltd is a technology company specializing in the research, development and service of automatic intelligent control, visual image identification. The company promotes series products of portable computer, industrial tablet pc, reinforced anti-riot army-regulation computer, non-fan Embedded IPC, X-RAY foreign matter detector, basket washing machine, slicer and turnover washing machine. The products have been applied in the military industry, telecommunication, metallurgy, transportation, electricity, railway, aviation, communication, finance, network, medical treatment, machine manufacturing, precise instrument, food processing and other sectors extensively.
