423740 Small Lithium Polymer Battery Lithium Polymer Battery 3.7v 620mah

Name: 423740 Small Lithium Polymer Battery Lithium Polymer Battery 3.7v 620mah
Brand: Cyclenpo
SKU: 122604451
Availability: InStock

Negotiable MOQ: 300 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Cyclenpo

Model Number:

po044040

Shenzhen Cyclen Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Cyclenpo

Model Number po044040

Type Li-polymer

Nominal Voltage Other, 3.7V

Size Other, H4.2 *W37.0 *L 40mm

Nominal Capacity 620mah

Cyclen energy,Clean your life.

423740 small lithium polymer battery lithium polymer battery 3.7v 620mah

Quick Details

Place of Origin:	Guangdong China (Mainland)	Brand Name;	Cyclenpo	Model Number:	p044040
Type:	Li-polymer	Nominal Voltage:	3.7v	Size:	according to customer requirement
Nominal Capacity:	620mah	color:	Silver	battery cell:	li polymer
Material:	li po battery	life cycle:	more than 500 times

Packaging & Delivery

Packaging Detail:	Original Package
Delivery Detail:	5-8 working days

Specifications

044040 li polymer battery 620mah 3.7v
1.Battery manufacturer
2.Environment friendly
3.High working voltage

044040Li polymer battery 450mah 3.7v

Special Features:

No	Item	Rated Performance		Remark
1	Rated Capacity	Typical	620mAh	Discharge at 0.6C after standard charge fully.
		Minimum	570mAh
2	Nominal Voltage	3.7V		Mean operation voltage during standard discharge.
3	Voltage at end of Discharge	3.0V		Discharge cut-off voltage.
4	Charging Voltage	4.2±0.03V
5	AC (1KHz) Impedance New Cell Max.(mW)	≤100mΩ
6	Standard Charge	Constant Current 0.5C Constant Voltage 4.2V 0.01 C cut-off		Charge time: Approx 4.0h.
7	Standard Discharge	Constant current 0.2 C end voltage 3.0V
8	Fast Charge	Constant Current 1C Constant Voltage 4.2V 0.01 C cut-off		Charge time: Approx 2.5h.
9	Fast Discharge	Constant current 1 C end voltage 3.7V
10	Maximum Continuous Charge Current	1.0C
11	Maximum Continuous Discharge Current	0.5C
12	Operation Temperature Range	Charge: 0~45°C		60±25%RH. Bare Cell.
		Discharge: -20~60°C
13	Storage Temperature Range	Less than 1 year: -20~25°C
		Less than 3 months: -20~40°C
14	Storage Humidity Range	60±25%RH.
15	Weight	Approx:13g		Whole product
16	Product Dimension	Length:Max4mm		Initial dimension
		Width: Max40mm
		Thickness:Max.40mm
