Specifications
10w 7pcs RGBW 4IN1 Mini LED Par CANS1. 7 x 10w LEDs
2. Channel: 4/8CHs
3. Amazing Dimmering, High brightness
7 x 10w RGBW 4 in 1 LED Par Cans Light
We are specializing in led stage light, Stage Equipment, disco light, club light and lighting accessories. We also supply OEM Service. Welcome to our website.
Technical Parameters
18x10W 4 in 1 LED CANS Light
Multi-voltage: 100-240VAC, 50/60Hz
Power Consumption: 180 Watts
Light source: 10w 4 in 1 LED's, Each LED have RGBW colors
Beam angle: 15degrees, 25degrees, 30degrees, 40degrees (selectable)
Silent operation, built-in a silent fan.
Long Life LED(rated at 100, 000 Hours)
Operational modes: DMX512, Master-Slave, Stand-Alone, Sound-activated
DMX-512 Protocol
4/8 DMX Channel Modes
3 pin XLR data input & output
Intelligent LED PAR 64
Electronic Dimming: 0 - 100%
Linear RGB color mixing allows for infinite color possibilities
Flicker free - ready for TV / Video use
Color strobe effect
Low power consumption
Mounting bracket designed for floor, wall or truss mount
Great for performance stages where traditional PAR cans emit a lot of heat onto performers
Smooth RGB color mixing (fast or slow color change operation)
N. W: 4KG G. W.: 4.5KG
Dimensions (LxWxH): 240X240X350MM
Packaging (LxWxH): 580x580x440mm (4PC/CTN)
DIAGRAM II
1 |
d001 |
4 channels, address adjustable by B & C button (001--255) |
2 |
d.001 |
8 channels, address adjustable by B & C button ( 001--255) |
3 |
CF.01 |
Gradual ,speed adjustable by B & C button (01-99) |
4 |
CC.01 |
Color change fast ,speed adjustable by B & C button (01-99) |
5 |
CS.01 |
Color Selection, While change color, with B & C button button (01-99) |
6 |
dENo |
Color combination. Speed adjustable by B or C button(01-99) |
7 |
bERT |
Sound active |
8 |
SLAV |
Slave accept and control according to master’s signal |
4Channels Mode | |
CH1 |
Red |
CH2 |
Green |
CH3 |
Blue |
CH4 |
WHITE |
8Channels Mode | |
CH1 |
Red |
CH2 |
Green |
CH3 |
Blue |
CH4 |
White |
CH5 |
Red,Green,Blue,White Linear 0%--100% |
CH6 |
Strobe Effect (Slow to fast from 001-255)
|
CH7 |
Mixed Color Lambency Effect |
CH8 |
STAND-ALONE |
Note: LED Par Lights are lights which feed us when the company is founded. We are famous for LED Par Light. Any different type of par light can be tailored. Welcome any request.
