Deacription:
Chocolate moulding line
The processing line can continuously produce various kinds of chocolate products. It is an automatic equipment which consists of process steps of accurate depositing, pistol central liquid-filling, vibrating, cooling, moulds turn-over, de-moulding ,mould-drying, and etc.. It can produce out good quality chocolate products such as “two color”, “central filling”, “lollipop(baby face) “chocolates.
PROCESS FLOWING CHART :
Oil melting, Sugar grinding---Fine milling—Chocolate mixing and temperature keeping—regulating---depositing---cooling----final products
FEATURES:
1) This line can produce the” pure” chocolate,”central-filling”, “two-color double layer “chocolate products. It is an ideal line for produce good quality chocolate products.
2) Moulds can be made according to the chocolate samples provided by the customer.
TECHNICAL SPECIFICATIONS:
Model |
CD100 |
CD200 |
Production capacity ( kg/h) |
100 |
125 |
Max. of the central-filling ( g) |
30 |
30 |
Speed of stroke ( n/min) |
15~25 |
15~25 |
Electric power needed |
15-18kw |
21kw/380V |
Refrigerator |
I: 4000 kcal/h II: 25000~30000 kcal/h |
|
|
Compressed air consumption Compressed air pressure |
0.2-0.4Mpa |
|
|
Conditions needed for the cooling system: 1.Room temperature(℃) 2.Humidity (%) |
20~25 55 |
|
Dimension(LxWxH mm) |
18330x1210x2500 |
36500 x1520 x2700 |
Gross weight (Kgs) |
5000 |
8000 |
Size of mould |
100-200pcs |
220-300pcs |
Qity of mould |
L300*W220*H30mm |
L300*W220*H30mm |
Samples:
Wooden Packing
1.Product production is completed, by the quality inspection department to check
2.After inspection qualified, clean for whole machine
3.Packing:
a.Inside the machine put desiccant
b.Add 6 cm thick foam plate around the machine,Then, winding stretch film for reinforcement, and combined with bubble wrap c.On wood packaging on the outside of the machine, then use metal reinforcement with steel
4.Container:according to different products for reinforcement
After-sale service for abroad customers.
1. Free training of macine installion, operation and maintenance will be provided by our engineer.
2. Some spare parts will be sent with the machine for free. It is available to buy the parts from us forever at low price.
3. We will surpport customers after-service forever by call, email and video etc.
4. If necessary, our engineer is available to go to customer's factory for machine installion and adjustment
Why choose us?
·Nearly 20 years experiences in food processing machinery production, established in 1982.
·We are manufacturer and wholesale of dough kneading machine
·We adopt environment-friendly materials and technology
·We mainly sell stock in bulk. OEM orders are welcome
·We can accept the mix order
