Fully Automatic hard candy machine line
The processing line is an advanced and continuous plant for making different sizes of hard candies and lollipops. It is an ideal equipment which can produce out good quality products with the saving of both the manpower and the space occupied.
1) PLC /computer process control available;
2) An LED touch panel for easy operating;
3) The standard production capacity is from 150kgs/h to 600kg/h;
4) The main parts is made of hygienic Stainless Steel
5) Optional (mass) flowing controlled by Frequency inverters ;
6) In-line injection, dosing and pre-mixing techniques for the proportional addition of liquid;
7) Dosing pumps for the automatic injection of colors, flavors and acids;
8) Use automatic steam control system instead of manual steam valve which controls stable steam supply to the microfilm cooker;
9) “two-color stripe depositing”, “two–color double layers depositing”, “central filling”, “clear” hard candies and etc. can be made.
10) Moulds can be made according to the candies samples provided by the customer.
PROCESSING CHART:
Raw material melting → Conveying → Filter → Storage → Constant syrup conveying →
Pre-heating → Micro-film vacuum cooking → Discharging → Mixing with flavor and Color
→ Depositing → Cooling → De-moulding → Conveying → Packing
Wooden Case
1.Product production is completed, by the quality inspection department to check
2.After inspection qualified, clean for whole machine
3.Packing:
a. Inside the machine put desiccant
b. Add 6 cm thick foam plate around the machine, Then, winding stretch film for reinforcement, and combined with bubble wrap
c. On wood packaging on the outside of the machine, then use metal reinforcement with steel
4.Container:according to different products for reinforcement
Shanghai Target Industry Co., Ltd is the sales and service company for Shanghai SHINWEI Machinery Manufacturing Co., Ltd which is the first manufacturer to build the complete production line for depositing hard candies in China and has accumulated 40 years’ fabrication experience. It is also one of the leading and professional exporters in China by providing customers home and abroad with high quality confectionery, chocolate, biscuit and packaging machinery. Our machineries have been exported to East European, south America, middle east, southeast Asia.
As the first-class corporation for fabrication of confectionery, chocolate, biscuit and packaging machinery, Target Industry offers not only the advanced equipment with competitive and economical efficiency, but the whole solutions for the customer's demands also. We provide the design, production, assembly and commissioning work of small or medium confectionery and biscuit machines in accordance with the customer's specific requirements.
After-sale services for all the customers
a. Free training of machine installation, operation and maintenance will be provided;
b. Some spare parts will be sent together with the machine for free and some spare parts are always at favorable price for regular customers;
c.Technical support will be offered by call, email or video etc;
d.If necessary, our engineer will go to your factory for machine installation, adjustment or maintenance.
Fully Automatic hard candy machine line
Model |
GD150B |
capacity(kg/h) |
150-200KG/Hr |
The candy weight |
According to the type of sugar |
Speed |
25~30 n/min |
Demand steam |
250-300kg/h, 0.5~0.8MPa |
Compressed air requirements |
0.25m 3 /min, 0.4~0.6MPa |
Machine power |
30kW/380V |
Machine line length (m) |
17 |
Machine line weight(Kg) |
3000 |
