Specifications
Rubber dynamic hardness TesterRubber dynamic hardness Tester
Test Mechanism
RCC-I Rubber Dynamic Cutting Tester uses a special-designed blade(Cutter)to repeatedly hit the rotating wheel-like rubber specimens with a certain force. It is aimed to simulate the situation when the rubber materials hit sharp objects with substantial force and are cut through, or when the rubber materials are tore apart on rough road surfaces by pulling braking or cutting actions. The testing results are presented in a similar way by the weight difference of the specimen before and after the test.
Technical parameters:
Impact frequency |
1,1.5,2±0.03Hz |
Impact distance |
48 ±1 mm |
Tip angle of blade |
60° |
Edge sharpness of blade |
0.015~0.020 mm |
Edge width of blade |
6.3mm |
Static load on the specimen |
475±10g |
Specimen size |
Φ50mm × 12mm |
Specimen rotating speed |
360,720,1080,1440±1 r/min |
Specimen rotating speed |
1~99min adjustable |
Working power supply |
220V/50Hz |
Rubber dynamic hardness Tester
