Specifications
Fatigue tester/cracking tester/flex durability testerISO6943, ISO132
Digital setting
Display in LCD screen
Security protect
De Mattia Flex Cracking Tester
Fatigue tester/cracking tester/flex durability tester
FT300 De Mattia Flex Cracking Tester
De Mattia Flex Cracking Tester is used for testing the abilities of vulcanized rubber, rubber shoes, thermoplastic and other materials crack after repeated flexing performance. It is produced following ISO6943, ISO132.
Features:
Digital setting, display the cracking number in the Counter LCD screen.
During one test, test can be paused or stop automatically when finished.
Maxium to 16 pcs sample and each sample can be clamped individually, easy to operate.
With security features on the up cover.
Specification:
Test Speed |
300r/min±10r/min |
Maximum number of samples |
16 pcs |
Reciprocating travel distance |
0~100mm |
Sample holder dimensions |
70mm X30mm |
Maximum force in traction |
600N |
Counter |
Digital counter, 0~999999 |
Safety devices |
Safety cover |
Dimensions |
430mmX430mmX720mm |
Weight |
55kg |
Power |
AC220V,50HZ,3A |
FT300 Tests
FT300 has stationary parts, provided with grips for holding one end of each of the test pieces in a fixed position, and similar but reciprocating parts for holding the other end of each of the test pieces. The travel of the up and low grips can be adjusted to fit different tests. FT300 use two equal groups for testing, so that one group is being flexed while the other group is being straightened, thus reduce the vibration in the machine.
Flex cracking and crack growth test for vulcanized rubber or thermoplastic
Test Standard: ISO132
Figure 1---De Mattia cracking test
1-upper grip 2- lower grip a-Travel
Determination of tension fatigue of vulcanized rubber
Test Standard: ISO6943
Dimension |
Type 1 |
Type 1A |
Type 2 |
|
A |
Overall length,min. |
115 |
100 |
75 |
B |
Width of ends |
25±1 |
25±1 |
12.5±1 |
C |
Length of narrow parallel-sided portion |
33±2 |
20 |
25±1 |
D |
Width of narrow parallel-sided portion a |
6.0 |
5±0.1 |
4.0±0.1 |
E |
Small radius |
14±1 |
11±1 |
8±0.5 |
F |
Large radius |
25±2 |
25±2 |
12.5±1 |
a The variation within any one die shall not exceed 0.05mm. | ||||
Figure 2---Dumb-bell test pieces
De Mattia Flex Cracking Tester
Fatigue tester/cracking tester/flex durability tester
