Product Description
500kg/h Wafer production line
Full - automatic wafer production line is designed and manufactured according to the facts of domestic biscuit manufacturing industry and absorbing the most well-known wafer production lines of many oversea manufacturers,which features reliable performance, compact structure, small occupation, high yield, lower energy consumption, convenient maintenance, simple operation. It consists of baking oven, cooling tower, sheet picking machine, cream spreading machine, cooling cabinet, cutting machine, batter mixer, cream mixer and smash machine. The driven motors adopt SEW Germany, the bearings use SKF France. Operating system uses PLC programming to make the process automated and easy control.
Wafer production line Technical parameters
| Type | WH-27 | WH-39 | WH-45 | WH-6351 | WH-63 | |
| Production(kg/h) | 250 | 350 | 450 | 500 | 600 | |
| Gas oven | Gas consump | 18 | 25 | 25 | 32 | 40 |
| Power (kw) | 2.2 | 2.2 | 3.3 | 3.5 | 3.5 | |
| Electrical | Installed volume | 120 | 160 | 180 | 200 | 250 |
| Baking plate electrical consumption | 86 | 124 | 144 | 163 | 201 | |
| Overall dimension(mm) | 5930*1500*2500 | 8330*1500*2500 | 9470*1500*2500 | 10610*1500*2500 | 12890*1500*2500 |
Shipment
500kg/h Wafer production line
Wooden packing
1.Product production is completed, by the quality inspection department to check
2.After inspection qualified, clean for whole machine
3.Packing: a. Inside the machine put desiccant b. Add 6 cm thick foam
plate around the machine, Then, winding stretch film for reinforcement, and
combined with bubble wrap c. On wood packaging on the outside of the
machine, then use metal reinforcement with steel
4.Container:according to different products for reinforcement
Wafer production line Services
500kg/h Wafer production line
After-sale services for all the customers a. Free training of machine installation, operation and maintenance will be provided;b. Some spare parts will be sent together with the machine for free and some spare parts are always at favorable price for regular customers;c.Technical support will be offered by call, email or video etc;d.If necessary, our engineer will go to your factory for machine installation, adjustment or maintenance.
Company Information
500kg/h Wafer production line
Shanghai Target Industry Co., Ltd is the sales and service company for Shanghai SHINWEI Machinery Manufacturing Co., Ltd which is the first manufacturer to build the complete production line for depositing hard candies in China and has accumulated 40 years’ fabrication experience. It is also one of the leading and professional exporters in China by providing customers home and abroad with high quality confectionery, chocolate, biscuit and packaging machinery. Our machineries have been exported to East European, south America, middle east, southeast Asia.
As the first-class corporation for fabrication of confectionery, chocolate, biscuit and packaging machinery, Target Industry offers not only the advanced equipment with competitive and economical efficiency, but the whole solutions for the customer's demands also. We provide the design, production, assembly and commissioning work of small or medium confectionery and biscuit machines in accordance with the customer's specific requirements.
Strength
500kg/h Wafer production line
Why choose us?a.Established in 1982, nearly 20-year experiences in the area of machinery manufacturing of food processing;b.Cooperate with well-known enterprises for some mechanical parts;c.Adopt environment-friendly and food-grade materials;d.Offer customized machineries and give suggestion for plant layout.
If you interested in our products,please contact us.I will spare no effort to help you!
