Full-Automatic Biscuit Production Line For Hard Biscuit and Soft Biscuit
Biscuit can be grouped into hard biscuit, cookie biscuit, according to the formula, process, and different forming method, Hard biscuit production line is generally composed of a feeding machine(if producing the soda biscuit or chocolate coated biscuit, another lamination process is needed), a set of dough roller, through the dough rolling and dough sheeting, then through the roller cutting machine, rest material recycling device, inlet oven machine, the entire biscuit forming line. For soft biscuit and cookie biscuit production line, only the forming machine and inlet oven machine can be the whole forming process. In order to increase the biscuit types and characteristics, customers can allocate the sugar & salt sprinkling machine, egg spraying machine, calico printing machine, etc. The oven is to make the formed biscuit into delicious food. You can choose different types of bakery oven(electric/gas/diesel/thermal oil)for baking different types of products. Dough rolling width is 250mm to 1200mm(if you have special needs, we can customized for you).
Full-Automatic Biscuit Production Line For Hard Biscuit and Soft Biscuit
Model |
BCQ250 |
BCQ400 |
BCQ600 |
BCQ800 |
BCQ1000 |
BCQ1200 |
Remark |
Capacity(kg/h) |
100 |
250 |
500 |
750 |
1000 |
1250 |
Up to |
Length(mm) |
29600 |
64500 |
85500 |
92500 |
125000 |
125000 |
No U turn |
Bake temperature |
190-240℃ |
190-240℃ |
190-240℃ |
190-240℃ |
190-240℃ |
190-240℃ |
190-240℃ |
Power(kw) |
65 |
190 |
300 |
380 |
700 |
830 |
Electric oven |
Weight(kg) |
6000 |
1200 |
20000 |
28000 |
35000 |
45000 |
approx |
Wooden Case
1.Product production is completed, by the quality inspection department to check
2.After inspection qualified, clean for whole machine
3.Packing:
a. Inside the machine put desiccant
b. Add 6 cm thick foam plate around the machine, Then, winding stretch film for reinforcement, and combined with bubble wrap
c. On wood packaging on the outside of the machine, then use metal reinforcement with steel
4.Container:according to different products for reinforcement
After-sale services for all the customers
a. Free training of machine installation, operation and maintenance will be provided;
b. Some spare parts will be sent together with the machine for free and some spare parts are always at favorable price for regular customers;
c.Technical support will be offered by call, email or video etc;
d.If necessary, our engineer will go to your factory for machine installation, adjustment or maintenance.
Shanghai Target Industry Co., Ltd is the sales and service company for Shanghai SHINWEI Machinery Manufacturing Co., Ltd which is the first manufacturer to build the complete production line for depositing hard candies in China and has accumulated 40 years’ fabrication experience. It is also one of the leading and professional exporters in China by providing customers home and abroad with high quality confectionery, chocolate, biscuit and packaging machinery. Our machineries have been exported to East European, south America, middle east, southeast Asia.
As the first-class corporation for fabrication of confectionery, chocolate, biscuit and packaging machinery, Target Industry offers not only the advanced equipment with competitive and economical efficiency, but the whole solutions for the customer's demands also. We provide the design, production, assembly and commissioning work of small or medium confectionery and biscuit machines in accordance with the customer's specific requirements.
