Push Pull RF Catv RF Amplifier Modules BGY888 BGY588 BGE788 BGD814 BGY67A BGY887B BGE788B

Specifications

push pull gas catv rf amplifier modules with wafer bgy888 bgy588 bge788 bgd814 bgd812 bgy67a bgr269,using for catv amplifier

FEATURES
Excellent linearity
Extremely low noise
Silicon nitride passivation
Rugged construction
TiPtAu metallized crystals ensure
Optimal reliability.

DESCRIPTION
Hybrid amplifier module for CATV
Systems operating over a frequency
Range of 40 to 550 MHz at a voltage
Supply of +24 V (DC) and intended for
Use as a line-extender.

LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 134).

Data Sheet Status
Objective specification This data sheet contains target or goal specifications for product development.
Preliminary specification This data sheet contains preliminary data; Supplementary data may be published later.
Product specification This data sheet contains final product specifications.
Limiting values
Limiting values given are in accordance with the Absolute Maximum Rating System (IEC 134). Stress above one or more of the limiting values may cause permanent damage to the device. These are stress ratings only and operation of the device at these or at any other conditions above those given in the Characteristics sections of the specification is not implied. Exposure to limiting values for extended periods may affect device reliability.

Application information
Where application information is given, it is advisory and does not form part of the specification.

LIFE SUPPORT APPLICATIONS
These products are not designed for use in life support appliances, devices, or systems where malfunction of these products can reasonably be expected to result in personal injury. Philips customers using or selling these products for
Use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such improper use or sale.  FEATURES
