Home > Packaging & Printing > Packing Machinery > Sealing Machine > Trouble Free Running Automatic Multi Head ROPP Cap Sealing Machine

Trouble Free Running Automatic Multi Head ROPP Cap Sealing Machine

Trouble Free Running Automatic Multi Head ROPP Cap Sealing Machine thumbnail-1
Trouble Free Running Automatic Multi Head ROPP Cap Sealing Machine photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type:
Bags, Barrel, Belt, Bottles, Cans, Capsule, Cartons, Case, Film, Foil, Pouch, Stand-up Pouch
Contact Supplier Request Quote Chat Now
Shree Bhagwati Pharma Machinery Company
Payment & Shipping
Payment Methods:
Port of Shipment:
India
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type Bags, Barrel, Belt, Bottles, Cans, Capsule, Cartons, Case, Film, Foil, Pouch, Stand-up Pouch
Packaging Material Glass, Metal, Paper, Plastic, Wood
Automatic Grade Automatic
Driven Type Electric
Voltage 415 Volts
Place of Origin Gujarat, India
Brand Name Shree Bhagwati Machtech (India) Pvt. Ltd.
Model Number SARCS - 200
Dimension(L*W*H) 2135 mm (L) x 1200 mm (W) x 2250 mm (H) Approx
Weight 1200 Kgs. Approx
Certification An ISO 9001:2000 Company
After-sales Service Provided Engineers available to service machinery overseas



Product Description



Automatic ROPP cap sealing machine is versatile, self-supported on stainless steel leg with height adjustable adjustment system. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are provided to facilitate the servicing of machine.





Operation:







The feed container moving on conveyor belt are feed into an infeed star wheel through In-feed worm, star wheel bringing the container below the sealing head in the subsequent indexing part,mean while the bottle pickup a cap from the delivery chute of cap filling bowl, where the body and the neck of the container are positioned below the rotating head, where the sealing head is performing perfect operation of threading & sealing.



Trouble Free Running Automatic Multi Head ROPP Cap Sealing Machine



Specification



Model
SARCS -100
SARCS - 150
SARCS - 200
  Output / Hour   3600 to 6000 Bottles   3600 to 9000 Bottles   4000 to 12,000 Bottles
  Direction of Movement   Left to Right
  Number of head   4 Nos.   6 Nos.   8 Nos.
  Electrical
  Specification 		  Main Motor   1.5 HP / 415 Volts / 50 Hz.   2 HP / 415 Volts / 50 Hz.
  Cap feeding Bowl   0.25 HP / 415 Volts / 50 Hz.   0.25 HP / 415 Volts / 50 Hz.
  Height of Conveyor **   860 mm to 910 mm
  Machine Dimensions **   2135 mm (L) x 1120 mm (W) x 2250 mm (H)   Approx   2135 mm (L) x 1200 mm (W) x 2250 mm (H)   Approx
  Case Dimensions   2650 mm (L) x 1250 mm (W) x 2250 mm (H)   Approx   2650 mm (L) x 1320 mm (W) x 2250 mm (H)   Approx
  Net Weight   900Kgs. Approx   1200 Kgs. Approx
  Gross Weight   1250 Kgs. Approx   1300 Kgs. Approx   1550 Kgs. Approx
  Change parts required   (A) Container: Star Wheel, Center guide, Feed Worm. (B) Cap: Die, Delivery chute, bowl.





ROPP Cap Specification   Diameter** Height**   19 mm to 38 mm** 15 to 18.3 mm
  Container Size**   Round Shape   (A) Ø 22 mm to Ø 100 mm ***
  (B) Height 58 mm to 240 mm***
  (Height option for other bottle height available)
  Flat / Square   (A) 15 mm to 100 mm (Lenght)
  (B) 10 mm to 50 mm (Width)
  (C) 58 mm X 240 mm (height)***(Height option for other bottle height available)
