Specifications
1. Bonding metal, plastic, painted materials etc.2. High solvent resistance
3.High adhesion
4.Good temperature resistance
Production Description:
3M™ VHB™ Tape RP16(F) is double-sided pressure sensitive adhesive tapes for bonding a variety of substrates including many metal, plastic and painted materials.
Production Construction:
Adhesive |
Multi-Purpose Acrylic |
Adhesive Carrier |
Conformable Acrylic Foam (closed cell) |
Density |
45 lb./ft.3 (720 kg/m3) |
Liner |
Paper Liner Version:White DK paper (red 3M™ VHB™ print) |
Film Liner Version:Red PE film (white 3M™ VHB™ print) | |
Tape Color |
Grey |
Available Size:
tandard Length |
72 yds. (65.8 m) |
Minimum Width |
1/2 in. (12.7 mm) |
Slitting Tolerance |
± 1/32 in. (0.8 mm) |
Core Diameter (ID) |
3.0 in. (76.2 mm) |
Typical Physical Properties and Performance Characteristics:
Peel Adhesion(stainless steel) |
12 lb./in. width (210 N/100 m |
Normal Tensile(alum T-block) |
95 lb./in² (655 kPa) |
Dynamic Shear:(stainless steel) |
90 lb./in² (620 kPa) |
Stainless Shear |
72°F (22°C) 1000 g/0.5 sq. in. (holds 10,000 min.) |
Solvent Resistance |
High |
Temperature Resistance |
Short Term (minutes, hours):250°F (121°C) |
Long Term (days, weeks):200°F (93°C) |
Storage:Store in original cartons at 70°F (21°C) and 50% relative humidity.
Shelf Life:When stored under proper conditions, product retains its performance and properties for 24 months from date of manufacture.
Applications:
-Closed cell
-Resist to UV light and chemicals.
-Used for bonding of glass, metal, plastic, wood, printing surface, etc.,
-Initial tape application to surfaces at temperatures below 50°F (10°C) is not recommended.
This Industrial Adhesives and Tapes Division product was manufactured under a 3M quality system registered to ISO 9001: 2008 standards.
