Help CenterPlastic Fish Farming System
Related Products
Build a fish farming cage system , you only need those material as below
1. pontoon cubes as the main buoyancy productions , you could build different size fish farming cage with it
2. fish nets
those product don't pollute environment like other Foam products , and the lifespan is 15years
pontoon cubes for fish farming cage (size :1000x500x400mm)
Effect drawing of fish farming cage , we could design it according your need .
fishing pontoon cubes Specifications:
Dimension: 500mm×500mm×400mm(L*W*H) & 1000*500*400MM (L*W*H)
Weight: 7.0Kgs/ pc ± 0.3Kgs/ pc
Floating Capacity: 350Kgs/ M2
Raw Material: HDPE
Preference Temperature: -60°C/+80°C Color available: orange, blue, gray, black
Load Capacity:
each one square meter is made up of four pontoons, top load is 325kgs.
Draft without load: 2.5-3cm;
Draft with load of 150kgs: 15-20cm(safe);
Draft with load of 300kgs:35-40cm(load limit)
Anti Wind Wave:
1.The wave on water surface between 2-class and 3-class belongs to safe applicable range.
2.The wave on water surface between 3-class and 6-class can be applicable; however,the safety protection must be reinforced.
3.The wave on water surface between 6-class and 9-class is the restricted applicable range (it is suggested that the shipping shall not be parked and the visitors shall not be in or out).
New float for fish farming cage
