Specifications
>plywood laminating machine>High quality, factory price
>Hot function and cold function
>High speed
Plywood laminating machine
(Chunlei Company Machine)
Description
CLF series Flatbed Laminators are designed for signage and graphic industries, used special for flexible sign, boards, irregular shaped panels, banners etc. It will not restrict by any width and length compare to traditional laminators. This laminator becomes the most cost effective and accurate method of applying self-adhesive materials, application tapes and digital prints to virtually any commonly used substrate in sign and graphics,promotional display and digital printing industries. CLF Flat machine aviable in different size , Such as 1.3m , 1.7m and 2m width . Working tables mainly have 2.5m , 3m , 3.6m
Technical data
Model |
CLF1325-B3 |
Application |
Laminating flatbed materials |
Maximum Working width |
1270mm |
Rollers Dia |
130mm ,Silicon |
Pressure/Height adjust |
Air pressure |
Max laminating temperature |
120°C |
Heating mode |
Infrared inner heating |
Laminating speed |
0-7m/min |
Roller lifting height |
50mm |
Roller Pre-heating time |
10-15 min |
Power supply |
AC220±10% 50HZ,Optional 110v,60HZ |
Heating power |
2000 W |
Net Weight |
350KG |
Size |
660×2150×1450(mm) |
Laser eye |
Yes |
Optimum performance
1 . Apply vinyls,graphics,digital prints or application tape to many substates
2 . Heat-assist cold lamination for clear output
3 . Fast processing with a speed up to 7m/min,Minimises waste and produces perfectly flat applications without bubbles and creases.
4 . Fully adjustable nip-gap and pressure for precise application
5 . The illuminated glass bed provides excellent back lighting
6. Side trays available eaiser application
Our company produce different model flat laminator machine , such as CLM1350-B2 , CLM1950-B2 ,CLF1325-B3 , CLF1325-B4 . If you need more information about our machine , please free to contact us
