Two Layers Laminating Machine

Name: Two Layers Laminating Machine
Brand: yuerte
SKU: 122458685

US$ 15,000 - 30,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Other, Machinery & Hardware

Packaging Type:

Other, Wooden case

Suzhou Yuerte Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Other, Machinery & Hardware

Packaging Type Other, Wooden case

Packaging Material Wood

Automatic Grade Automatic

Driven Type Electric

Voltage 380V 50HZ

Power 15kw

Place of Origin Jiangsu, China

Brand Name yuerte

Model Number YET07-01

Weight 2000KG

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.For all basis materials.
2.It can be made with slitting fuction if req.
3.Full or semi-auto of unwinding/winding tension.

Double-layer lamination machine(YET07-01)

Application:

Suitable for the lamination rewinding of the basis materials, such as PET, PE, PP, double-side tape, release paper, Mylar etc.

Feature:

All basis materials double-layer lamination rewinding, wide range of application.
There will be with the function of slitting if required---lamination slitter rewinder.
Full automatic or semi-automatic control of unwinding/winding tension.
Centralized control, easy operation.

Model	YET-700	YET-1000	YET-1300	YET-1600
Raw material width	700 mm(Max.)	1000 mm(Max.)	1300 mm(Max.)	1600 mm(Max.)
Raw material diam	600 mm(Max.)	600 mm(Max.)	600 mm(Max.)	600 mm(Max.)
Finished product width	40-700 mm	40-1000 mm	40-1300 mm	40-1600 mm
Finished product diam	400 mm(Max.) Design upon the request of customer
Inside diam of paper core	3”
Mechanical speed	0-60 M/min
Voltage	220V/ 380V/440V 3-Phase 50/60 Hz
