Interior Yellow Wall Insulation Fiberglass Mesh/gridding Screen Cloth(China Factory&manufacturer)

Interior Yellow Wall Insulation Fiberglass Mesh/gridding Screen Cloth(China Factory&manufacturer) thumbnail-1
Interior Yellow Wall Insulation Fiberglass Mesh/gridding Screen Cloth(China Factory&manufacturer) photo-1
US$ 0.1 - 0.25 MOQ: 10000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
Dehong
Model Number:
Fiberglass Mesh
Contact Supplier Request Quote Chat Now
Anping County Dehong Metal Mesh Products Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name Dehong
Model Number Fiberglass Mesh
Application Wall Materials
Weight 50-160g/m2
Width 1-2m,1-2M
Mesh Size 8x8,10x10,12x12mm
Weave Type Plain Woven
Yarn Type C-Glass
Alkali Content Alkali Free
Standing Temperature Medium

Specifications

Interior yellow wall insulation fiberglass mesh/gridding screen cloth
Mesh Dia:8x8;10x10;12x12mm
Breadth:0.6;0.9;1m
ISO9001



Interior yellow wall insulation fiberglass mesh/gridding screen cloth(China Factory&manufacturer)



1. Intro



On the alkali or alkali free glass fiber grid cloth weaving yarn, the alkali resistant polymer emulsion coated



glass fiber. Alkali grid cloth series products: GRC fiberglass mesh cloth, alkali resistance wall private network



and stone grid cloth, marble back grid cloth.



2. Application





1) wall enhanced material such as glass fiber wall mesh cloth, GRC wall panels, EPS exterior insulation board,
     gypsum board, etc.

2) reinforced cement products (such as the Roman column, the flue, etc. danyang Bosch molding co., LTD.

3) private networks (VPNS), granite, Mosaic marble back stick network.

4) waterproofing materials, asphalt roofing waterproof.

5) reinforced plastic, rubber skeleton material.

6) fire prevention board.

7) grinding wheel base fabric.

8) road surface with geogrid.

9) used in sealing belt and so on.

3. Interior Wall Products

GRC products made of reinforced with glass fiber grid cloth woven base material, the alkali resistant polymer

emulsion is handled and become, the product high strength, good alkali resistance, can be persistent

resistance to alkali stale and pedantic scholar, is the cement concrete products, GRC wall panels, GRC

components an ideal reinforcing material.

4. General Specification

1) mesh size: 8 mm x 8 mm to 10 mm x 10 mm to 12 mm x 12 mm

2) width: 60 cm, 90 cm 1 meter

3) weight: 125 g/m2

4) length: 100 meters or 50 meters/roll

5) colors; White (standard) yellow green or other colors.

6) Package: Carton, plastic bag, or according to customer requirements packaging.

7) special specifications and hardness can be made according to the customer requirement book.

5. Glass Fiber Adhesive Tape

1) Purpose: to repair the dry wall, plasterboard juncture, all kinds of wall cracks and other metope damaged
                   Glass fiber adhesive tape

2) Main performance: good alkali resistance, durability, high tensile strength and deformation resistance, anti
                                  crack: not bad, not bubble: good self-adhesive,

3) Don't need to advance on the coat, the use of quick and easy construction.

4) Specification: 8 x 8.9 x 9 mesh/inch: 55-85 g/m2. 000 mm

                width: 25-1000mm

               length: 10-153 m.

5) Color: usually in white.


6. Construction Method





1) The wall clean and dry.

2) The sticky tape and cracks in the pressure.

3) Confirm the gap has been cover tape, and then more tape measure with a knife cut, the last brush on
    mortar.

4) Allow it to dry naturally, then gently.

5) Fill enough paint, make its surface smooth.

6) Remove leak adhesive tape. Then, look at all the cracks are properly patched, around the seams with
   subtle composite modification, so that it is bright and clean like new.

7. Alkali Resistant Products

Its based on the alkali grid cloth or alkali-free glass fiber woven fabric as the foundation, the alkali resistant

coating processing and into. The product high strength, good alkali resistance, in the structure of heat

preservation system plays an important role, mainly to prevent the generation of cracks. Because of its

excellent resistance to acid, alkali and other chemicals stale and pedantic scholar latitude and longitude of

performance and to the high tensile strength, can make the external wall thermal insulation system of stress

evenly dispersed, can avoid because of outside force caused by the collision, squeezing the thermal

deformation of the structure, the thermal insulation layer with high impact strength, and easy to construction

and quality control, in the insulation system plays the role of "soft steel bar".

8. Current Standard

Exterior wall insulation technology in current national standards (JG149-2003) : to alkali resistant fiberglass

mesh warp and weft tensile breaking strength shall not less than 750 n / 50 mm, alkali resistant tensile

breaking strength retention rate shall not be less than 50%, the weight of every square metre 130 grams or

more. And JG158-2004 to alkali resistant fiberglass mesh warp and weft tensile fracture strength less than

1250 n / 50 mm, alkali resistant tensile breaking strength retention rate shall not be less than 90%, the weight

of every square metre 160 grams or more.

9.Common specifications

- 4 x 4 mm, 165 g/m2, 1 m x 50 m - 5 x5mm, 80 g/m2, 120 g/m2, 145 g/m2, - 250 - g/m2, 280 g/m2, 300 g/m2,

1 mx50m - 4 x 5 mm, 135 g/m2, 145 g/m2, 1 m x 100 m 7 x 7 mm, 140 g/m2

10. More Keywords



fireprood mesh net, plastic cloth, gridding cloth, fiberglass gridding cloth, fiberglass mesh, fiber glass cloth,



resistance mesh fabric, Alkali-resistance mesh, Alkali-resistance cloth, Alkali mesh fabric, interior wall



insulation glass fiber grid colth, outside wall reinforced glass fiber grid cloth, plain fiberglass gridding cloth,



reseau/grid/mesh/wires cloth/fabric



11. Pictures Show



Interior yellow wall insulation fiberglass mesh/gridding screen cloth(China Factory&manufacturer)
