One-loop Spiral Razor Barbed Wire Mesh/Plane Welding Razor Barbed Wire Mesh/Panel Razor

One-loop Spiral Razor Barbed Wire Mesh/Plane Welding Razor Barbed Wire Mesh/Panel Razor photo-1
One-loop Spiral Razor Barbed Wire Mesh/Plane Welding Razor Barbed Wire Mesh/Panel Razor photo-2
One-loop Spiral Razor Barbed Wire Mesh/Plane Welding Razor Barbed Wire Mesh/Panel Razor photo-3
One-loop Spiral Razor Barbed Wire Mesh/Plane Welding Razor Barbed Wire Mesh/Panel Razor photo-4
One-loop Spiral Razor Barbed Wire Mesh/Plane Welding Razor Barbed Wire Mesh/Panel Razor photo-5
US$ 356 - 756 MOQ: 100 Tons
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
dh
Model Number:
BTO-22
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hebei, China
Brand Name dh
Model Number BTO-22
Material Iron Wire
Surface Treatment Galvanized
Type Barbed Wire Coil
Razor Type Single Razor
Product Description
Product Description



 One-loop Spiral Razor Barbed Wire Mesh/Plane Welding Razor Barbed Wire Mesh/Panel Razor





Razor Barbed Wier Mesh is a new kind of security fence which is used widely in many countries.When you need to get serious about security,Razor Wire is the answer.



Razor Blade Specification:



Reference Number

Blade Style

Thick
ness

Wire Dia

Barb Length

Barb Width

Barb spacing

BTO-12



0.5
±0.05

2.5
±0.1

10
±1

13
±1

26±1

BTO-18



0.5
±0.05

2.5
±0.1

15
±1

15
±1

33±1

BTO-22



0.5
±0.05

2.5
±0.1

22
±1

15
±1

34±1

CBT-65



0.6
±0.05

2.5
±0.1

65
±2

21
±1

100±2



Barbed Tape Wire Specification:



Outside Diameter



No. of Loops

Standard Length per Coil

Type

Notes

450mm

33

8M

CBT-65

Single coil

500mm

41

10M

CBT-65

Single coil

700mm

41

10M

CBT-65

Single coil

960mm

53

13M

CBT-65

Single coil

500mm

102

16M

BTO-10.15.22

Cross type

600mm

86

14M

BTO-10.15.22

Cross type

700mm

72

12M

BTO-10.15.22

Cross type

800mm

64

10M

BTO-10.15.22

Cross type

960mm

52

9M

BTO-10.15.22

Cross type







Notes:


Standard products are shown in the tables above, special specifications available on request.
Standard materials are either galvanized or stainless steel.



One-loop Spiral Razor Barbed Wire Mesh/Plane Welding Razor Barbed Wire Mesh/Panel RazorOne-loop Spiral Razor Barbed Wire Mesh/Plane Welding Razor Barbed Wire Mesh/Panel RazorOne-loop Spiral Razor Barbed Wire Mesh/Plane Welding Razor Barbed Wire Mesh/Panel RazorOne-loop Spiral Razor Barbed Wire Mesh/Plane Welding Razor Barbed Wire Mesh/Panel RazorOne-loop Spiral Razor Barbed Wire Mesh/Plane Welding Razor Barbed Wire Mesh/Panel Razor
