YQC660 belt roller vegetable cutting machine, CHINA FD vegetable cutter
- 100 Unit / Units per Month
- Qingdao
- T/T
Product Details
| Condition: | New | Place of Origin: | Shandong, China | Brand Name: | New Golden dragon |
| Model Number: | YQC-660 | Type: | Cutter | Voltage: | 220V/380V |
| Power(W): | 1500w | Weight: | 120KG | Dimension(L*W*H): | 900*460*740 |
| Certification: | ISO9000 | Warranty: | 1 year | After-sales Service Provided: | No overseas service provided |
Product Description
YQC660 belt roller vegetable cutting machine details:
The YQC660 type multifunction vegetable cutting machine is also suitable for rhizome, long stems, leaves, fruits and vegetables shredding ,cutting, dicing: cabbage, celery, leek, rape etc.
Multifunction vegetable cutting machine can cut our common vegetables, cutting high efficiency, uniform cutting, slicing, shredding, diamond, we can customize tooland provide machine spare parts.
Characteristics:
slice thickness : 1-5mm
shredding thickness : 1-20mm)
New Golden Dragon cutting machine using 201 thick stainless steel without magnetic sheet, long-term use does not rust. Centrifugal drum is entirely made of aluminum magnesium alloy and stainless steel materials, health and durable, long-term work does not rust. Copper core motor configuration.
The chopping machine produced by our company is divided into various types, can cut all kinds of fruits, vegetables, please call detailed consultation.
The main structure and working principle:
1.It is mainly composed of a machine frame, conveying belt, the pressure belt,food slicing mechanism, a speed regulating box or cone pulley speed regulating mechanism.
2. centrifugal slice mechanism for melon potato hard vegetables slices, slice thickness can be adjusted freely in a certain range, the vertical knife can be leafy softdish or sliced sheet processed into different specifications of the block,piece,diamond and other shapes. Cutting length by "adjustable eccentric" arbitrarily in a certain range of adjustment. Because of the vertical. knife hand cutting machining simulation principle, smooth surface, regular shape, cut vegetables are well organised, keep fresh.
3. try before cutting, the cut vegetables to observe the specifications and requirements of specifications, otherwise should adjust the slice thickness orcutting length, to meet the requirements of the normal work.
4. cutting machine installed vertical knife: first turn the adjustable eccentric wheel,make the cutter frame to after bottom dead center, and then make the knife up to 1-2mm, vertical knife in contact with the conveyor belt, the fastening nuts to the vertical knife fastened on the tool carrier. Description: turret lifted height according to the cut vegetables on their own hands. If the turret lifted height is small, vegetables may evenknife turret lifted; if the height is too large, may cut the conveyor belt.
Cutting length adjustment:
The chopping machine adjustment: turn the adjustable eccentric connecting rod,loosen the fastening screws, cut filaments movable fulcrum, from outside to inside (atthe openings shall be upward), cut thick wire when the movable fulcrum, from inside to outside (at the openings shall be down), after a good tune fastening adjustment screws.
Factory show:
Packing & Shipping:
1) Packaging: we advise wooden frame case pacakge to avoid damage of the products.
2) Shipping: we advise sea shipping to save money, because the product is heavy and the package is big.
