Help Center800kg/h Cotton Fiber / Polyester Fiber / Fiber Openning Machine
Related Products
-
T01 Polyester Fiber / Kapok / Wool Opening MachineUS$ 1,000 - 100,000MOQ: 1 Unit -
Polyester Fiber Fine Opening MachineUS$ 4,000 - 6,000MOQ: 1 Set
-
Fiber Opening Machine in Fiber OpenerUS$ 1,000 - 20,000MOQ: 1 Set
-
Fiber Opening Machine /wool Cutting Machine for SaleUS$ 1,000 - 30,000MOQ: 1 Unit
-
T01A Polyester Fiber / Kapok / Wool Opening MachineUS$ 1,000 - 100,000MOQ: 1 Unit
Specifications
High capacity100% opening rate
1 labor
roller made by V-wire
Item no.: |
T01A |
T01B |
T01D |
T01E |
T01F |
Dimension |
2400*1010*1010mm |
2400*1100*1010mm |
2530*2010*1240mm |
2530*1510*1240mm |
2530*1720*1240mm |
Voltage |
380V 50Hz 3phase |
380V 50Hz 3phase |
380v 50Hz 3phase |
380v 50Hz 3phase |
380v 50Hz 3phase |
Power |
6.25KW |
6.25kw |
15.2kw |
13.2kw |
13.2kw |
Working width |
710mm |
790mm |
1500mm |
1000mm |
1200mm |
Capacity |
±200kg/h |
±300kg/h |
±900kg/h |
±500kg/h |
±700kg/h |
Opening rate |
98% up |
98% up |
98% up |
98% up |
98% up |
Weight |
580kg |
680kg |
1200kg |
980kg |
1000kg |
Material application:
- Conjugate hollow siliconized PSF, 7D-15D, 32MM-64MM
- Micro fiber: 0.7D-3D, 32MM-64MM
- Fire prove polyester fiber
Description:
- The fiber opening machine is mainly used for opening conjugate hollow siliconized polyester fiber that short than 100mm length.
- Automatic raw material feeding conveyer function is to send the material into the opening rollers automatically, so that assures the operators safety.
- Anti-deviation conveyer system to assure a long life conveyer.
- The developed rollers are assembled with metallic V-wire that the fiber can be opened for more than 98% to 100% and not be damaged.
- High opening capacity that can be 200kg to 900kg per hour according to different machine model and the material.
- Roller balance processing
- Overload protection
- Long life operation and lower repairing rate
- It can be handled by only one operator with simple operation.
- Mechanical and electrical safety standard is acceptable by Eu market that meets the UL and CE rules.
Roller made by V-wire, wihch is very stable and long life, the opening rate can b emore than 98%.
Opened fiber
SERVICE:
We are able to supply machine commissioning support and training
oversease for larger automatic machine lines.
Please contact us as soon as any problem happends with some photos and
descriptions; our engineers will response within 24 hours with technical
instructions.
All spare parts are standard that can be found from local.
We will send it to you by overnight if needed.
Service Translator: Ms. Jenny
CUSTOMER LOCATION:
Australia,Aruba, Armenia, Bangladesh, Brazil, Belgium,Canada, Cyprus,
Columbia, Denmark,Egypt, Estonia, Greece, Hungary, Holland, India,Italy,
Indonesia, Iran, Jordan, Korea, Mexico, Philippine, Poland, Paraguay, Russia,
South Africa, Spain,Slovenia, Thailand, Turkey, UAE, UK, USA, Chile,
Vietnam, Ageria, Argentina, Saudi Arabia, Bulgaria, Dubai, Czech
Republic, Zimbabwe, Libya,Maldives,Lithuania, Lebanon, Malaysia,
Macedonia, Moldova,Nigeria, New Zealand, Portugal, Japan, Switzerland,
Serbia, Cyprus, Tunisia, Venezuela, Uruguay, Singapore, Iraq,
