Garlic Drying Machine With Safty Devices

Garlic Drying Machine With Safty Devices photo-1
Garlic Drying Machine With Safty Devices photo-2
Garlic Drying Machine With Safty Devices photo-3
Garlic Drying Machine With Safty Devices photo-4
Garlic Drying Machine With Safty Devices photo-5
Garlic Drying Machine With Safty Devices photo-6
US$ 18,000 - 22,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Farm Equipment
Use:
Grain
Certification:
CE ISO
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Type Farm Equipment
Use Grain
Certification CE ISO
Place of Origin Anhui, China
Brand Name CHENYU grain dryer
Model Number 5HCY-15J
Condition New
After-sales Service Provided Engineers available to service machinery overseas
Product Description

I.10T-15T Functional Characteristics

wide application
rice/paddy/wheat/corn/rapeseed/soybean/pea
high drying speed
reduce  1% moisture per hour on average
indirect heating technology
less pollution and more safty
low temperature
60℃-120℃
crack rate
<3%
grind rate
<0.5%
II.Low-temperture Grain Dryer Specification




garlic drying machine with safty devices

Model
5HCY-15J
Loading capacity
Paddy(kg)
2300-15000
Wheat(kg)
2700-15000
Weight (kg)
3200
Dimension(mm)
H
10370
L
4320
W
2492
Ventilation Fan
Model
4-72-6A
Rated air flow(m3/h)
6677-13353
Husk Burner(optional)
Model
indirect hot air heating(automatic temperature control)
Ignition mode
manual
Fuel consumption(kg/h rice hull)
30-40
Fuel
rice hull,firewood,straw,anthracite
Electric Power
Voltage/Frequrecy
three phase 380V,single phase 220V/50Hz
Total Motor power (kw)
7.5kw
Function
Loading time(min)
paddy   55-70
wheat   50-65
unloading time(min)
paddy   55-70
wheat    50-65
Drying rate (%/h)
0.8-1.5
Device
Safety Device
full load buzzer,thermal-over relay,temperature controller,hot air temperature sensor,overload protection device,leakage protection device
Standard Device
online moisture monitor,grain temperature sensor,fault removal sensor
1.Specification is subject to change without notice.
2.The parameters are just for reference.The moisture of the paddy is from 24% to 15% and 28% to 12.5% for wheat.Actual datas will be differed from variety,moisture content and temperature.
Detailed Images

Blower

1 set 4KW(10T/12T/15T)

SS steel sheet in Cross Flow type

Thickness 1.0mm,Mesh 2.0mm

Electronic Control Cabinet

Full-automatic touch screen

easy to operate&maintain

Packing & Delivery

Inner Package with stretch film

outside package with standard export wooden

Inner Package with stretch film

Our Service

Pre-sales: Answer technical questions and the introduction of products for clients according to their demand and provide customers a complete solution;

Sales: Provide product installation; improve the instruction for use and maintenance manual. It is free to provide technical training until the customer can operate the products independently;

After-sales: Offer one year of warranty from the date of installation and acceptance. And also provide life-long maintenance and repair services. Engineers available to service overseas;

contact person
Lisa Du
Mobile
+86 18626059928
skype
ahladujuan
QQ
2360393622
Our Company

Anhui Chenyu Mechanical Co.,Ltd,aiming at grain dryer business,is a comprehensive agricultural machinery manufacturer&national enterprise that specializes  in the integration of development,manufacturing,sales and services.In a high speed,we develop three  Subsidiary company.

1.Major in producing grain dryer&husk burner over 12 years

2.Have sold  over 7500 sets machines in the domestic and overseas.

3.Awarded over 30 patents and passed the identification of popularizing agricultural

4.Invest over RMB 200 millions on R&D

The 5H series low-temperature circulating grain dryer and CY5L series husk burner are our main products.We have core patents,can ensure exact security and energy saving  on grain drying process.

With the core value"Drying perfect,saving efficient",hope we can contribute a force for you.

Certifications

The above is our company honors.

You can contact with us directly and know more about details.


The above is our company patents.
You can contact with us directly and know more about details.

FAQ

1. How about engineers service oversea?
    Engineers available to service machinery overseas;

2.. How about the guarantee period?
    One year.

3. Will you accept L/C as payment?
    L/C is accepted. T/T is OK for us.
    Alibaba Trade Assurance is your best choice.

4.What type of dryers do you have? Are these continuous or batch?

    Batch type.Low-temperature circulating grain dryer.

5.what is the minimum seed size that your machine can handle ?

     2.0mm

6.Would you like to provide a solution on the machine setting?

    Yes,we'd like to.Please share your daily capacity,grain moisture content,fuel type,etc.
