Cross Flow Type High Quality Lentil Bean Drying Machine

Cross Flow Type High Quality Lentil Bean Drying Machine thumbnail-1
Cross Flow Type High Quality Lentil Bean Drying Machine thumbnail-2
Cross Flow Type High Quality Lentil Bean Drying Machine thumbnail-3
Cross Flow Type High Quality Lentil Bean Drying Machine thumbnail-4
Cross Flow Type High Quality Lentil Bean Drying Machine thumbnail-5
Cross Flow Type High Quality Lentil Bean Drying Machine thumbnail-6
Cross Flow Type High Quality Lentil Bean Drying Machine photo-1
Cross Flow Type High Quality Lentil Bean Drying Machine photo-2
Cross Flow Type High Quality Lentil Bean Drying Machine photo-3
Cross Flow Type High Quality Lentil Bean Drying Machine photo-4
Cross Flow Type High Quality Lentil Bean Drying Machine photo-5
Cross Flow Type High Quality Lentil Bean Drying Machine photo-6
US$ 16,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Grain Processing Equipment
Use:
paddy seed processing machine
Certification:
ISO
Contact Supplier Request Quote Chat Now
Anhui Chenyu Mechanical Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Grain Processing Equipment
Use paddy seed processing machine
Certification ISO
Place of Origin Anhui, China
Brand Name CHENYU
Model Number 5H-12
Condition New
After-sales Service Provided Engineers available to service machinery overseas
Our Company

Anhui Chenyu Mechanical Co.,Ltd,aiming at grain dryer business,is a comprehensive agricultural machinery manufacturer&national enterprise that specializes  in the integration of development,manufacturing,sales and services.In a high speed,we develop three  Subsidiary company.

1.Major in producing grain dryer&husk burner over 12 years

2.Have sold  over 7500 sets machines in the domestic and overseas.

3.Awarded over 30 patents and passed the identification of popularizing agricultural

4.Invest over RMB 200 millions on R&D

The 5H series low-temperature circulating grain dryer and CY5L series husk burner are our main products.We have core patents,can ensure exact security and energy saving  on grain drying process.

With the core value"Drying perfect,saving efficient",hope we can contribute a force for you.

Certifications

The above is our company honors.

You can contact with us directly and know more about details.


The above is our company patents.
You can contact with us directly and know more about details.

Product Description

I.10T-15T paddy seed processing machine Functional Characteristics

wide application
rice/paddy/wheat/corn/rapeseed/soybean/peanut/other seeds
high drying speed
reduce  1% moisture per hour on average
indirect heating technology
less pollution and more safty
low temperature
40℃-75℃
crack rate
<3%
grind rate
<0.5%
II.Dryer for paddy used Specification


Cross flow type high quality lentil bean drying machine
Model
5H-12
Loading capacity
Paddy(kg)
2300-12000
Wheat(kg)
2700-12000
Weight (kg)
2800
Dimension(mm)
H
9030
L
4320
W
2492
Ventilation Fan
Model
4-72-6A
Rated air flow(m3/h)
6677-13353
Husk Burner(optional)
Model
indirect hot air heating(automatic temperature control)
Ignition mode
manual
Fuel consumption(kg/h rice hull)
30-40
Fuel
rice hull,firewood,straw,anthracite
Electric Power
Voltage/Frequrecy
three phase 380V,single phase 220V/50Hz
Total Motor power (kw)
6.8
Function
Loading time(min)
paddy   50-60
wheat   45-55
unloading time(min)
paddy   50-60
wheat    45-55
Drying rate (%/h)
0.5-1.2
Device
Safety Device
full load buzzer,thermal-over relay,temperature controller,hot air temperature sensor,overload protection device,leakage protection device
Standard Device
online moisture monitor,grain temperature sensor,fault removal sensor
1.Specification is subject to change without notice.
2.The parameters are just for reference.The moisture of the paddy is from 24% to 15% and 28% to 12.5% for wheat.Actual datas will be differed from variety,moisture content and temperature.
Detailed Images

Blower

1 set 4KW(10T/12T/15T)

SS steel sheet in Cross Flow type

Thickness 1.0mm,Mesh 2.0mm

Screw Conveyor

1pc upper screw conveyor&4 pcs lower screw conveyor(10T/12T/15T)

Packing & Delivery

paddy seed processing machine inner package with stretch film

paddy seed processing machine outside package with standard export wooden case

paddy seed processing machine inner package with stretch film

Our Service

Pre-sales: Answer technical questions and the introduction of products for clients according to their demand and provide customers a complete solution;

Sales: Provide product installation; improve the instruction for use and maintenance manual. It is free to provide technical training until the customer can operate the products independently;

After-sales: Offer one year of warranty from the date of installation and acceptance. And also provide life-long maintenance and repair services. Engineers available to service overseas;

FAQ

1. How about engineers service oversea?
    Engineers available to service machinery overseas;

2.. How about the guarantee period?
    One year.

3. Will you accept L/C as payment?
    L/C is accepted. T/T is OK for us.
    Alibaba Trade Assurance is your best choice.

4.What type of dryers do you have? Are these continuous or batch?

    Batch type.Low-temperature circulating grain dryer.

5.what is the minimum seed size that your machine can handle ？

     2.0mm

6.Would you like to provide a solution on the machine setting?

    Yes,we'd like to.Please share your daily capacity,grain moisture content,fuel type,etc.


MORE CHOICES,BETTER BUSINESS.



contact person
Lisa Du
whatsapp  (mobile)
+8618626059928
skype
ahladujuan
wechat
ahladujuan_lisa
QQ
2360393622
Customer Case

three dryers supported by one Furnace

Building Plant

six  dryers supported by one Furnace
