RJW851 series -4 new heavy type water jet loom with super high speed, stable running and wide adaptability

Specifications

1, DESIGNED RPM:1200
2,MTU and MLO
3,ELECTRONIC FEEDER
4,DENKEN ELECTRIC FEEDER
5,CAM SHEDDING, DOBBY SHEDDING OR JACQUARD

RJW 851 SERIES NEW TYPE HEAVY WATER JET LOOM:



Main features:



RJW851 series -4   Single-pump two-nozzle cam shedding type heavy water-jet loom

> Optional: mechanical let-off mechanism, mechanical take up mechanism, electronic let-off mechanism, electronic take up mechanism.

> Optional: RDP mechanical measuring & storage device, 1-6 nozzle electric weft selecting freely.

> Configurable shedding devices: cam shedding; dobby shedding, jacquard.

> Optional reed width: 135,150,170,190,210,230,260,280,300,320,340,360CM

> The weft density range: 4-100 pick/cm (Identified according to actual weft yarn specifications and fabric weave).

> Maximum speed: 800RPM/min (Identified according to actual weft yarn specifications and fabric weave).

> Heald frame number: crank shedding 2-8 pieces; cam shedding 2-14 pieces; dobby shedding 16 pieces.

> Install power: 2.8kw-5.4kw
