Help CenterRJW408-190cm Dobby Water Jet Loom
Related Products
-
Tsudakoma 300 Type Water Jet Loom -power LoomUS$ 8,700 - 13,000MOQ: 1 Piece -
RJW408 WATER JET LOOM CAM SHEDDINGUS$ 9,000 - 12,000MOQ: 1 Piece
-
Water Jet LoomUS$ 9,000 - 18,000MOQ: 1 Piece
-
RJW408-150CM Dobby Water Jet LoomUS$ 6,000 - 8,000MOQ: 1 Piece
-
RJW408-190cm WATER JET LOOM DOUBLE NOZZLEUS$ 15,000 - 280,000MOQ: 1 Piece
RJW408 IS SPECICALLY SESIGNED FOR TWILL AND SATIN FABRIC,WHICH HAVE HIGH SPEED,HIGH EFFICIENCCY AND STEADY OPERATION.THUS IS PERFORMS VERY WELL IN WEAVING TWIL AND SATIN FABRIC.
THE OPTIONAL MACHAINICAL WEFT STORAGE DOBBY SHEDDING AND TAPPET SHEDDING CAN BE MOUNTED ON THIS TYPE LOOM,ENLARGING THE WORK ABLE RANGE FROM VARIOUS THIN TO THICK FABRICS.
THE RJW 408IS GOT WHOLE IN NOVATION APPLICABLE TO WEAVING HIGH WEAGHT AND HIGH DENSITY CLOTH ,THE GREAT IMPROVEMENT OF VIBRATION REDUCTION ,THE EXCELLENT STABILITY,THE HIGH SPEED AND HIGHER EFFICIENCY CAN BE SUITABLE FOR WEAVING MEDIUM AND PREMIUM CLOTH
SIX nozzle dobby shedding water jet loom
Specifications of RJW water jet loom | |||
Type |
RJW851 |
RJW408 |
|
Reed space |
150,170,190,210,230,260,280,320,340,360,(cm) |
||
Useful reed space |
Nominal R/S minus 2cm to 50cm |
||
Frame |
Box frame type( Driving section is in an oil bath) |
||
Driving |
Brake |
Direct stop mechanism by an electromagnetic brake |
|
Control |
Push and touch button(Arrange, run, stop, forward inching, reverse inching, one step reverse) |
||
Motor |
Rush start motor |
||
Motor capacity |
1.5KW, 1.8KW, 2.2KW, 2.8KW, 3.2KW, 3.7KW, 4.5KW. |
||
Beating |
Crank beating |
||
Let-off |
System |
Automatic mechanical and continuous let-off, or electronic let-off. One or vertical two roll |
|
Warp beam |
800MMFlange,178MMbarrel |
||
Take-up |
System |
Mechanical or electronic continuous take-up |
|
Pick density |
Normal:5-60picks/cm,Special:3-70picks/cm |
||
Cloth wind-up diameter |
420mm, 520mm, 600mm. |
||
Shedding |
Plain shedding |
Crank shedding( heald frame number:2 to 6), 1/1 fabric |
|
Cam shedding |
Cam shedding ( heald frame number:2-10),plain, twill, satin fabric |
||
Dobby shedding |
Positive/negative Heald frame number:16(max),electronic and mechanical reading system, plain, twill, satin or complex design |
||
Jacquard |
1408, 2688, 5120 lifting hooks, electronic jacquard device |
||
WeftInsertion |
Measuring & storage |
300RDP type mechanical measuring turbo blower(single nozzle) or electronic weft feeder(1-4 nozzles) |
|
Pump |
Type: M,L,H, single or double |
||
Piston of pump |
32/17,32/18,32/20,36/22,36/24,36/26, 39/26,39/28,39/30,50/35,ceramic piston |
||
Nozzle needle |
ST20/10, ST30/10, ST45/20, SD75/40. |
||
Weft filling |
One, two, three, four nozzle |
||
Filling feeler |
Electronic, optical, and self-control |
||
Selvage |
Twisting by star, planetary gears |
||
|
Electrical Part |
Made in China import |
Main control board, AC contactor, transformer, NC interface, selvage break system ,waste yarn break system, overheating and overload protection |
|
|
Electronic meter |
.Count and display: rotational speed, total yield, team yield, total efficiency, team efficiency Cloth length auto control, Stopping analysis and display |
||
Other devices |
A cloth roller, a weft density gear, a trashcan ,a set of nozzle needle |
||
