Specifications
AM CB Radio KT-CB806 With Signal Strength Indication ,CB Mobile AM HF Radio TransceiverQuick Details
| Place of Origin: | Fujian China (Mainland) | Brand Name: | JIMTOM | Model Number: | KINGTONE |
| Type: | Vehicle Mouted | Dimensions: | 165(W)x116(H)x44mm(D) | Frequency Range: | 25-28MHz |
| Storage Channel: | 40 | Talk Range: | 20KM | Color:: | Black |
| Display: | LCD | Output power: | 12W | Emergency channel 9/19: | Yes |
| RSSI:: | Received Signal Strength Indication | Weight:: | About 1.0kg |
Packaging & Delivery
| Packaging Detail: | gifty box line with safety foam |
| Delivery Detail: | 5-10 days after order comfirmed or opun the quantity |
Specifications
CB Mobile AM HF Radio Transceiver
1.Frequency:25-28MHz
2.12W 40 channels
3.PA Function
4.Received Signal Strength Indicat
1.AM CB RADIO
2.12W, 40 Channels
3.25MHz-28MHz
4. PA Function
5.Signal Strength Indication
FEATURE:
Radio frequency range: 25-28MHZ (customized available)
40 channels
Transmitted power:12V
Emergency channel 9/19
PA function
RSSI (Received signal strength indication)
TECHNICAL INFORMATION
RF output > 12W
Frequency response: 300-2500Hz
Power source: 13.8V DC
Audio output load: 16 OHM Resistive
Audio output: 5W (or more)
Sensitivity:
12dB sinad under 1.0Uv RF Signal or less
Intermediate frequency: 1st IF-10.7MHZ, 2nd IF-450KHZ
Technology Specification:
GENERAL |
|
Frequency range |
25-28 MHz (optional) |
Channel |
40 |
Channel spacing |
10kHz |
Frequency stabilization |
±2.5ppm |
-20°C~+60°C |
|
Voltage |
13.8V |
Standby current |
About 25mA |
Size |
165 (W)×116(H)×44mm (D) |
Weight |
About 1000g |
TRANSMITTER |
|
RF power output |
12W |
Emission current |
3A |
Modulation |
AM |
Residual radiation |
<-60dB |
RECEIVER |
|
Reference sensitivity |
1uV (12dB SINDA) |
Squelch sensitivity |
-107dbm |
Inter-modulation anti-interference |
>60dB |
Audio power |
4W |
Standard Package Contains:
1 x CB-80 Radio
1 x Speaker Mic
1 x Mounting Bracket
1 x DC Cable
1 x English Manual
Warranty: One year for Radio / Six Month for Accessory.
