Portable Downspout Gutter and Elbow Machine,Downspout Systerm

Wuxi Friendship Machinery Co., Ltd.
Portable Downspout Gutter and Elbow Machine,Downspout Systerm thumbnail-1
Portable Downspout Gutter and Elbow Machine,Downspout Systerm thumbnail-2
Portable Downspout Gutter and Elbow Machine,Downspout Systerm thumbnail-3
Portable Downspout Gutter and Elbow Machine,Downspout Systerm thumbnail-4
Portable Downspout Gutter and Elbow Machine,Downspout Systerm thumbnail-5
Portable Downspout Gutter and Elbow Machine,Downspout Systerm photo-1
Portable Downspout Gutter and Elbow Machine,Downspout Systerm photo-2
Portable Downspout Gutter and Elbow Machine,Downspout Systerm photo-3
Portable Downspout Gutter and Elbow Machine,Downspout Systerm photo-4
Portable Downspout Gutter and Elbow Machine,Downspout Systerm photo-5
US$ 8,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Tile Forming Machine
Tile Type:
Steel
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Tile Forming Machine
Tile Type Steel
Use Roof
Production Capacity 100%
Place of Origin Jiangsu, China
Brand Name FSM
Model Number FSM-001703
Power(W) 5.5kw
Voltage 380V/50HZ/3P
Dimension(L*W*H) 2500 x 500 x 1500
Weight 600kg
Warranty 12MONTHS
After-sales Service Provided Engineers available to service machinery overseas

Main Technical



Standard Features:

Polyurethane power drive system

Two 360 degree Rotatable Reel Stands with Easy Lift Reels.

Stainless steel forming rollers

Electric Motor 3/4Hp, 220V 50Hz or customized

Push Button RUN/JOG controls at Entry and Exit Ends

Welded Tubular Steel Frame

Forward Pulling, Easy Cut Shear

Specifications:

5” and 6” combo gutter machine

Length*Width*Height: 3m*0.6m*1.2m

Weight: 610kg.



Materials Formed

l Painted Aluminum : 0.5mm to 0.8mm

l Copper : 0.5mm to 0.7mm



Shear:

Manually Powered, Hardened Tool

Steel Blade and Dies



Coil Width:

5” Machine:300mm to 315mm

6” Machine:380mm



Speed:

About 15m/min



Profile drawings:



Standard 5” gutter profile

 Portable Downspout Gutter and Elbow Machine,Downspout Systerm

Standard 6” gutter profile

Portable Downspout Gutter and Elbow Machine,Downspout Systerm

We have all machines of downspout systerm

Including downspout machine, gutter machine, elbow machine.

Industry type,portable type,some machine with wheels,moveable

If you are interested,pls contact us.

Portable Downspout Gutter and Elbow Machine,Downspout SystermPortable Downspout Gutter and Elbow Machine,Downspout SystermPortable Downspout Gutter and Elbow Machine,Downspout Systerm

Portable Downspout Gutter and Elbow Machine,Downspout Systerm
