Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > High PF>0.95 t8 9w 18w TUBE Light Led Driver dc 36-88vconstant Current 230 240 MAH Quality Choice
High PF>0.95 t8 9w 18w TUBE Light Led Driver dc 36-88vconstant Current 230 240 MAH Quality Choice
US$ 0.89 - 0.89
MOQ: 200 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
JSR
Model Number:
T8-18W led tube driver
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN YANTIAN or SHEKOU
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Isolated High PF48w Led Driver AC85-265V 1100MAH for Panel Light and Flood LightUS$ 4 - 4MOQ: 50 Pieces -
IP68 High PF Isolated 100w 3000MAH Led Driver for Outdoor Lights Quality ChoiceUS$ 7.5 - 7.5MOQ: 200 Pieces
-
20000RPM Professional Electric Manicure Machine Electric Nail Drill Art Pen Pedicure Bits Quality ChoiceUS$ 4 - 5.5MOQ: 200 Pieces
-
Nail Dust Collector Reviews For Nails Beauty Support 110/220V-240V Voltage BeigeUS$ 15 - 18MOQ: 1000 Pieces
-
Pobling Ultrasonic Face Brush Eletrical Cleansing Tool Machine Pore Sonic CleanserUS$ 6 - 8MOQ: 200 Pieces
Place of Origin
Guangdong, China
Brand Name
JSR
Model Number
T8-18W led tube driver
Output Power
1 - 50W
Output Type
Single
Input Voltage
Other, AC90-265V
Output Voltage
36v
Output Frequency
50-60hz
Output Current
230mah
Features:
1. Universal AC input / Full range (up to 320VAC)
2. OVP to prevent electronic components from damage caused by voltage instability.
3. Brand driver IC: brand constant current IC solution,high constant current presision+-3%
4. Isolated design,flicker free, Low THD<20%.
5. 3 years warranty:25000 - 30000 hours.
6. 4KV transformer,top brand IC
7. Constant Current
8. Built-in active PFC function
9. High efficiency up to 91.5%.
High PF>0.95 t8 9w 18w led TUBE light driver dc 36-88vconstant current 230 240 MAH
| Features of LED tube drivers | ||
| Output | no-load Max voltage | 120V±5% |
| constant current range of application | 36-85V | |
| constant current | 220 - 300MA | |
| string quantity | 24 string | |
| Power Range | 8W/10W/12W/15W/18W/20W/24W/25W/26W/28W/30W/32W/35W/40W/45W/48W/64W | |
|
ripple wave and noise Max |
500mvp-p | |
| constant current erro | ±3% | |
| load adjustment rate | ±3% | |
| start,rise time | <3S 230VAC full load | |
| maintain time | 10ms 230VAC full load | |
| Input | voltage scope | 90V~265V |
| Frequency scope | 47~63HZ | |
| power factor | PF≥0.97 230VAC( full load rated output voltage) | |
| efficiency(230V AC) | ≥0.95 | |
| alternating current | 0.123A/230AC | |
| surge voltage | 30A/230V | |
| leak current | <0.15MA/265AC | |
| Protection | Over-protection current | protection type:stop work,rocover after unusual remove |
| short circuit protection | protection type:stop work,rocover after unusual remove | |
| thermal protection | protection type:stop work,rocover after unusual remove | |
| Environment | working environment | 20%~90% |
| working temperature | -40~+80°C | |
| storange temperature, humidity | -40~+80°C,10~95%RH | |
| temperature factor | ±0.03%/°C | |
| Others | size | Customized |
| Adaptor | EFD(more big better for heat dissipation | |
Applications
Packing:
Shipping
Our services
1.CE/ROHS certificates are approved.
2.strict quality control.
3.Quick delivery,for the stocks only take 1 days. some OEM orders takes 1 week.
4.Factory wholesale price .
5.All your questions or requirements will be taken by our sales .
6.Our engineer team will develop new products for the work team .
