Automatic Plastic Pipe Belling Machine for socketing
- 5 Set / Sets per Month
- Shanghai port
- T/T
- CNC router for stone processing engraving machine
- Glass polishing machine JMB95A
- Aluminum Profile Bending Machine/Arc Bending Machine for Aluminum
- Automatic aluminum window corner connector cutting machine
- aluminum door and window frame cutting machine aluminum windows and doors machine
- Upvc Window Door Machine Four Head Welding Machine for PVC welding Window Machine
Product Details
Condition: | New | Type: | Pipe Belling Machine | Pipe Material: | PVC |
Application: | Drain Pipe | Production Capacity: | Max.40 pieces/h | Place of Origin: | Jiangsu, China |
Brand Name: | FOSITA | Model Number: | SGK | Voltage: | 380v,50hz,3 phase |
Power(W): | 7.5KW | Dimension(L*W*H): | sized | Weight: | 2500kg |
Certification: | CE | Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Automatic Plastic Pipe Belling Machine for socketing
Automatic Plastic Pipe Belling Machine for socketing
characteristics:
1.High elasticizing capacity
2.Low energy consumption
3.High cost performance and long life
main technical parameters:
The outer diameter of the pipe: 50mm-160mm
Work Dimensions Length: 4 to 6 meters
Machine System:
Electric System, hydraulic system and machinery system.
Hydraulic system: Motor model of Oil Pump: Y100L1-4
Power: 2.2kw Rotation speed: 1430r/m
Oil Pump Model: V18-A1-R-A Rated Voltage: 6.3Mpa
Discharging Capacity: 0-18L/min
Working pressure of the system: 4-6.3Mpa
Hydraulic Oil: No.46 anti-friction hydraulic oil
Heating system:
Motor power of electric heating pipe of the Heating stove: 1kw×8=8kw
Maximum Temperature of the air: 380°C
Electric system:
Pressure of compressed air: 0.4—0.6Mpa
Pressure of water supply: 0.2—0.3Mpa
PLC Controller: FX1N-60MR-001+FX0N-40ER
Operating voltage: AC380V 50HZ
Total power of the unit: 10.5KVA
Total weight of the unit: 3600kg
Working center height: 1100±10MM
Production speed: about 30 nos/h
Outside dimension of the unit: 6800mmL×1800mmW×1850mmH
Suzhou Fosita Science and technology Co.Ltd is located in Zhangjiagang city Jiangsu Province, the economic booming area of Changjiang Delta.
Here is our CE certificate, we can provide you high quality production and excellent after-sale service.
Each year, there are many old and new customers come to our factory to have cooperation.
we have attended many trade fairs such as Chinaplas ,Arabplast,plastindia to show our product.
Our main products are PE/PPR/PVC pipe,WPC/PVC profile production lines,PET bottles and PP/PE films recycling line,Plastic wastes pelletizing lines, and all kinds of other auxiliary equipments,such as Mixer,Crusher,Pulverizer,Shredder,Water chiller and so on .Looking forward to cooperating with you!
Pre-sale services
1.Provide the free consultation of the machine
2.Provide the standard device and the flow chart
3.According to the clients’ special requirement, offering the reasonable plan and free design helping to select the machine
4.Welcome to visit our factory
Services during the sales
1.Help client design the factory and offering professional advice, free engineering drawing for the factory layout.
2.Inspect the machine before leaving the factory.
3.Send our experienced workers and engineer to your factory for installing and adjusting all the machine
4.Train the first-line operator.
5.Provide the basic formula
After sale services
1.One year warranty
2.24 hours online service
3.Engineers available to service machinery overseas
4.Provide technical exchanging
