Help Center2.54mm Pitch Female Header Connector
Related Products
-
Female HeaderUS$ 0.023 - 0.35MOQ: 2000 Pieces -
Female Header ConnectorUS$ 0.023 - 0.35MOQ: 3000 Pieces
-
Female Header Dual Row W/P And Local Peg SMT TypeNegotiableMOQ: 5000 Pieces
-
Female Header 1.00 Dual Row W/P SMT TypeNegotiableMOQ: 5000 Pieces
-
2.0mm Single Row SMT Type Female HeaderUS$ 0.05 - 0.5MOQ: 5000 Pieces
Detailed Product Description
1.Current Rating: 3.0A 2.Withstand Voltage: 600VAC/minute 3.Insulator Material: Polyester(UL94V-0)
SPECIFICATIONS:
Current Rating: 3.0A
Contact Resistance: 30MΩ Max
Insulation Resistance: 1000MΩ Min
Withstand Voltage: 600VAC/minute
Operation Temperature: -40ºC to +105ºC
MATERIALS:
Contact Material: Phosphor Bronze
Contact Plating: Gold or Tin over 50μ '' Ni
Insulator Material: Polyester(UL94V-0)
Standard: PBT
Others:
1. Pitch: 2.54mm
2. Insulator Height: 8.5mm
3. DIP Spacing: Triple Row
4. Number of Pins: 03~120Pin
5. Tail & Mounting Style: S=Syraight DIP Type
6. Contact Plated: Tin/Gold Flash(Gold 1u'')/Gold 3u''/Gold 5u''/Gold 10u''/Gold 15u''/Gold 30u''
7. Material Type: PPS/PBT/LCP/Nylon-66/Nylon-6T/PA6T
8. Package Options: Tube Tape and reel package
