1.27mm/2.00mm/2.54mm Right Angle DIP Type Box Header
Current Rating: 1.0A~3.0A
Contact Resistance: 30MΩ Max
Insulation Resistance: 1000MΩ Min
Withstand Voltage: 500VAC/minute
Operation Temperature: -40ºC to +105ºC
MATERIALS:
Contact Material: Brass
Contact Plating: Gold or Tin over 50μ '' Ni
Insulator Material: Polyester(UL94V-0)
Standard: PBT
Others:
1. Pitch: 1.27mm/2.00mm/2.54mm
2. Insulator Height: 5.6mm/5.8mm/7.1mm
3. DIP Spacing: Single row / Double row
4. Number of Pins: 10~64P
5. Tail & Mounting Style: S=Straight DIP type R=Right Angle DIP type M=Straight SMT type
6. Contact Plated: Tin/Gold Flash(Gold 1u'')/Gold 3u''/Gold 5u''/Gold 10u''/Gold 15u''/Gold 30u''
7. Material Type: PPS/PBT/LCP/Nylon-66/Nylon-6T/PA6T
