RoHS Compliance BOX header connector
- 500 Piece / Pieces per Month
- Shenzhen;HongKong
- T/T
Product Details
Place of Origin: | Guangdong, China | Brand Name: | LYCN | Model Number: | BH-033 |
Type: | Adapter | Application: | PCB | Gender: | Female |
Product Description
Specifications
2.54mm Right angle DIP type BOX Header connectorRoHS Compliance
Gold plated
Box Header
Specifications:
Current Rating:3.0 AMP
Contact Resistance:20mΩ Max
Insulation Resistance:1000MΩ MIN
Withstand Voltage:500 VAC/MIN
Operation Temperature:-40°C to +105°C
MATERIALS:
Contact Material: Copper Alloy
Contact Plating:Gold or Tin over 50µ" NI
Insulator Material:Glass Filled Polyester(UL94V-0) Standard:PBT
1.Series No: Box Header / Ejector Header
2.Pitch: 2.00*2.00mm
3.Insulation Height: 12.20mm / 15.00mm
4.Number of Contacts: 10 Pin~64 Pin
5.Tail& Mounting Style: Straight Dip Type
6.Contact Plated: Tin;Gold Flash;Gold 3µ"/5µ"/10µ"/15µ"/30µ"
7.Material Type: PPS/PBT/LCP/Nylon-66/Nulon-6T/PA46
8.Black/Blue/Red/White/Yellow/Grey
Company Profile
Shen Zhen Lycn Electronics Co., Ltd. is professional in the R&D, production and marketing of connectors for communication, computers, network, relays, instruments and electronic products.
Our company possesses advanced world-class processing and testing equipment from Switzerland, the US and Japan. We specialize in development and production of highly precise connectors. Main products are PIN connectors, round hole sockets, LCD sockets, PLCC sockets, PGA sockets, bull corners, coaxial connectors, round pin D-Sub connectors, USB connectors, pin headers and female headers.
With high quality materials and advanced equipment, we ensure that we can provide high quality products to our customer with competitive prices and timely delivery. We are able to respond quickly to dynamic market and constantly introduce new products. At the same time, we are able to provide customized total connector solutions.
With the trend of advance, precision and specialization of electronic products in the world, we constantly adhere to ISO9001:2008 quality system to assure our product quality. We hope that we will be pioneer of technology as well as of marketing.
We hope that we will become customers' partner and first choice. Promoting customer value through joint efforts is our prior task, which is also our behavioral principle. Therefore, we will keep consolidating our strength to comprehensively satisfy our customers and to develop our business in win-win situation with our customers.
