Help CenterHigh Quality DK-7132CHL 32ch D1 CIF Cctv P2P Cloud DVR ,Rack Mount, 8ch D1+24ch CIF Realtime Recording,4pcs HDD DVR
Related Products
-
DAKANG 4ch Dvr Surveillance System ,4ch 960H Real Time Cctv Dvr With RS485NegotiableMOQ: 1 Piece -
16CH Real Time Cctv DVR/HVR With HDMI and P2p,2ch D1+14CH CIFNegotiableMOQ: 1 Piece
-
16CH Port 960H@12fps,16ch D1 Real Time Cctv DVR, HDMI , P2p,2pcs SATA PortNegotiableMOQ: 1 Piece
-
16CH Port AHDL 960H@12fps,16ch D1 Real Time Cctv DVR, HDMI , P2p,1pcs SATA PortNegotiableMOQ: 1 Piece
-
Full D1/HDMI/AHDL 960H Economical Cloud DVR ,p2p CloudNegotiableMOQ: 1 Piece
Specifications
32ch (8ch D1+24CH CIF) standalone DVR16ch Audio/Alarm
4pcs SATA HDD,USB2.0,VGA ,HDMI
P2P cloud,support IP camera
Rack mount
DK-7132CHL Standalone DVR/NVR
Key Features:
*Support HDMI, VGA and CVBS synchronous output.
*Support zoom any area selected by the mouse under PELCO-D/P PTZ control protocol.
*Support one key to run recording function.
*Support holiday recording and snapshot setup.
*Support schedule snapshot, manual snapshot, alarm snapshot, FTP upload snapshot, playback and backup of the snapshot.
*Support search, playback, backup the recording according to events; support *playback and search pictures in local.
*Support smart search in the self-defined areas in the playback of the recording.
*Support 4 SATA ports.
*Support maximum 8 playback.
*Support NTP(Internet timing), DHCP(automatically get IP),Email(mail service),UPNP(Universal Plug and Play).
Picture:
Back panel:
Specification:
System |
Model |
DK-7124CHL |
DK-7132CHL |
Main processor |
High performance embedded microprocessor/HI3531 |
||
Operating system |
Embedded LINUX operating system |
||
Language |
English, Simplified Chinese , Traditional Chinese , Brazilian , Russian, Portuguese, Spanish , Italian , Korean , French , Czech , Hebrew , German , Finnish , Bulgarian , Swedish , Romanian , Greek, Etc. |
||
System resources |
Pentaplex function: Live, recording, playback, backup& remote access |
||
Control mode |
Front panel, USB mouse, Network, remote control |
||
Video |
Input |
24ch , BNC(1.0Vp-p, 75Ω) |
32ch , BNC(1.0Vp-p, 75Ω) |
Standard |
PAL / NTSC |
||
Output |
1 HDMI,1 TV, 2ch BNC,(1.0Vp-p, 75Ω), 1 VGA |
||
Audio |
Input |
16ch, RCA(200-2800mV,30KΩ) |
|
Output |
1ch, BNC(200-3000mV,5KΩ) |
||
Display |
Display split |
1/4/8/9/16/24/32 |
|
Resolution |
1920*1080,1280*720,1440*900,1280*1024, 1024*768,800*600 |
||
Tour display |
Support |
||
OSD |
Camera title, time, video loss, camera block, motion detection, recording |
||
Record |
Video/Audio compression |
H.264/G711 |
|
Image resolution |
D1(704 X 576/704 X 480), HD1(704 X 288/704 X 240), CIF(352 X 288/352 X 240) |
||
Encoding speed |
Main stream: CH1~8 D1(1~25/30FPS),CH9~24 CIF(1~25/30FPS) |
Main stream: CH1~8 D1(1~25/30FPS),CH9~32 CIF(1~25/30FPS) |
|
Extra stream: CIF(1~25FPS),QCIF(1~25FPS) | |||
Image quality |
1~6 level (level 6 is the best),VBR effectively |
||
Record mode |
Manual, schedule(always, motion detection, video lost, video blind, alarm), stop |
||
Record sequence |
Manual>Alarm>Motion detection>General |
||
Alarm |
Triggering event |
Record, Snapshot, Alarm, Email |
|
Motion detection |
Area: 396(22 * 18), Sensitivity: 1-6 level |
||
Video loss |
Support |
||
Alarm input |
16ch |
||
Alarm output |
4ch |
||
|
Playback and backup |
Playback channel |
8ch D1+8ch CIF synchronous playback |
|
Search mode |
Time/Date, Alarm, Motion detection & Exact search(accurate to second) |
||
Playback function |
Play, Pause, Stop, Fast play, Slow play, full screen, backup |
||
Backup mode |
Flash drive/USB HDD/Network download |
||
Network |
Interface |
RJ-45 port(10/100M) |
|
Network functions |
TCP/IP,UDP,DHCP,DNS,IPFilter,PPPOE,DDNS,FTP,Email,UPNP,Alarm Server,ARSP,3G,WIFI |
||
Remote operation |
Monitor, PTZ control, Playback, System setting, File download, Log information |
||
web browsers |
Internet Explorer(Support cloud server), |
||
P2P Cloud Service |
Support Cloud Server: , each DVR build-in a Serial Number |
||
Mobile Surveillance |
Support iPad& iPhone ,Android phone/( cloud APP: Vmeyecloud) |
||
Hard disk |
Interface |
4 SATA Ports, each port support max 3TB HDD |
|
management |
Hard disk standby technology, hard disk failure alarm |
||
Auxiliary interface |
USB port |
2 USB Ports: 1 for mouse control, 1 for backup |
|
RS485 |
PTZ Control |
||
Environment |
Power supply |
DC 12V ,6A |
|
Environment |
-10°C ~+55°C /10~90%RH/86~106kpa |
||
Dimension |
445*440*92MM |
||
Weight |
5.0KG(without HDD) |
||
Easy remote access from mobile phone and IE explorer:
A. Remote acecss from Mobile Phone:
1. Find the QR code at the bottom of DVR,like below:
2. Download APP: Vmeyecloud
3.login APP, Select "by Device","Add","Input Name" anyone,"SerialNo" input or Scan QR code, "User name" admin, "Password",no need fill, choose Cloud on, then Save thses,then go back,select your DVR .
B. Remote acecss from IE:
1. Login cloud server: http//,
choose "by Device"
2. input DVR serialNo and verify code.
Certificate:
OEM:
Customer Logo can be stuck/Printed on goods/color box upon confirmed.
Warranty
All our products have 2 years warranty.
Good news:
New economical POE NVR
IP cameras POE
NVR kits will be come out soon
