HTL-V420/V520/V680
Fully Automatic Vertical Packing Machine
for granule products, stripes, candy slices, potato chips, jelly, peanuts
Application:
The bagging machine is widely used for packing of products in shape of granules, stripes, slices, such as candy, potato chips, jelly, and peanuts.
Characteristics:
1. Touch screen with stable transmitting PLC control to perform bag making, weighing, filling, sealing, code printing, and cutting automatically.
2. Independent compressed air control and electrical wire system control separately, low noise in running, stable performance.
3. Vacuum belt pulling system to feed film and make bags with no faults.
4. Double servo control system, precise positioning.
5. Easy to palce the rewind rolls onto the machine.
6. Set uo and adjust parameters on touch screen to change bag size.
7. Sealed structure design to prevent dust contamination.
8. Multi computerized weighing heads to deliver correct weight.
Specifications:
Mode |
HTL-V420 |
HTL-V520 |
HTL-V680 |
Bag length(mm) |
80-300(L) |
80-400(L) |
100-480(L) |
Bag width(mm) |
50-200(W) |
80-250(W) |
180-320(W) |
Max width of roll film(mm) |
420 |
520 |
680 |
Packing speed(bags/min) |
5-60 |
5-50 |
5-50 |
Volumn range |
150-1200ml |
3000Max |
6000Max |
Air consumption(Mpa) |
0.65 |
0.65 |
0.65 |
Gas consumption(m3/min) |
0.3 |
0.4 |
0.4 |
Power voltage |
220V |
220V |
220V |
Power(KW) |
2.2 |
4 |
5 |
Dimension(L*W*H)mm |
1320*950*1360 |
1150*1795*1650 |
1780*1350*1950 |
Weight(kg) |
540 |
600 |
900 |
Packing Samples:
Real Machine photo:
Wooden box
Our company attends many fairs:
>>>Welcome to our factory!!!<<<
Haitel Machinery Co,. Ltd. is a professional manufacturer of automatic food processing and packing machinery for manufacturers making candy, chocolate, egg-rolls, cakes and other food. Specializing in confectionery processing equipment, our company has a professional team with strong techincal and R&D knowledge to develop advanced food equipments to cope with market changes.
Our important certificates:
Our products have been exported to over 80 countries all over the world:
