MILLING&DRILLING MACHINE MODEL ZAY7045
US$ 960 - 980
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
China
Brand Name:
WHITE EAGLE
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI CHINA
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Milling and Drilling Machine ZAY7020GNegotiableMOQ: 1 Set -
MILLING&DRILLING MACHINE MODEL ZAY7040A/1NegotiableMOQ: 1 Set
-
MILLING&DRILLING MACHINE MODEL ZAY7045US$ 999 - 1,020MOQ: 1 Set
-
Milling and Drilling Machine ZAY7025FGNegotiableMOQ: 5 Pieces
-
Milling and Drilling Machine ZAY7032FGNegotiableMOQ: 1 Set
Condition
New
Place of Origin
China
Brand Name
WHITE EAGLE
Model Number
ZAY7045
Type
Vertical
CNC or Not
Normal
Voltage
AS BUYER'S REQUIRED
Power(W)
AS BUYER'S REQUIRED
Dimension(L*W*H)
1020X820X1160MM
Weight
335KGS
Certification
ISO9001-2000 CE TUV
Warranty
ONE YEAR AFTER SALE
After-sales Service Provided
No overseas service provided
Product Description | |
| Belt-driven and round column | |
| Milling, drilling, tapping. Boring and reaming | |
| Headstock swivels 360 horizontally | |
| Micro feed precision | |
| 12 steps speed | |
| Adjustable gibs on table precision | |
| Posive spindle lock | |
| Strong rigidity, powerful cutting and precisely positioning. | |
| Model | ZAY7045 |
| Drilling capacity | 45mm |
| Face milling capacity | 80mm |
| End milling capacity | 32mm |
| Distance from spindle nose to table | 450mm |
| Min.distance from spindle axis to column | 203.5mm |
| Spindle travel | 130mm |
| Spindle taper | M.T.4 or R8 |
| Step of spindle speed | 12 |
| Range of spindle speed 50Hz | 80-2080 r.p.m |
| 60Hz | 100-2500 r.p.m |
| Swivel angleof headstock (horizontally) | 360° |
| Table size | 800×240mm |
| Forward and backward travel of table | 175mm |
| Left and right travel of table | 500mm |
| Motor Power | 1.5KW |
| Voltage/frequency | As customer’s requirement |
| Net weight/gross weight | 285kg/335kg |
| Packing size | 1020×820×1160mm |
| Loading amount | 28pcs/20 ’container |
Manufacturing Ability
PACKAGE &TRANSPORTATION
