DVI CABLES SERIES
DVI privide a high-speed digital connection unique for the digital display technology. This video interface technology maximizes the quality of flat-panel LCD monitors and high-end video graphics cards. DVI is becoming an industrial standard with graphics manufacturers, and most of the graphic cards are now designed for both a VGA and a DVI output. In addition to becoming the computer graphics' standard, DVI is also the digital transfer method for HDTV, EDTV, Plasma Display, and other high-end video displays (TV and DVD player).
Perfect for connecting your DVI Monitors, Projectors, and Video Cards.
Supports all high resolutions DVI monitors.
Superior performance, Guaranteed.
High-speed digital thansmission of up to 4.95Gbps.
Cable length:. Optional.
Cable connections: 18+1, 18+5, 24+1, 24+5.
Item No.: DD2005
Description: DVI & VGA Cable Series
Connector: Nickle or Gold plated connectors
Specification: 30AWG/28AWG/26AWG
Length: 0.5m/1m/1.5m/1.8m/2m/3m/5m/7.5m/10m or by customer request
Brand: bluede / OEM
Packing: PE bag, Blister packing or according to customers request
Description |
AWG |
Conductor |
Shield |
OD |
Impendance |
Pair Attenuation |
Pair Delay Skew |
|
MM |
MM |
Ω |
MHz |
dB/ft |
||||
|
Digital Single Link 4P+5C |
28 |
7/0.127 |
Al/My+Braid |
7.3 |
Pair:100 |
1 |
0.015 |
4.5ns/m Inter Pair:1.5ns Intra Pair:200ps
|
30 |
7/0.102 |
5.5 |
10 |
0.042 |
||||
|
Digital Dual Link 7P+5C |
28 |
7/0.127 |
8.5 |
50 |
0.08 |
|||
30 |
7/0.102 |
7.5 |
100 |
0.12 |
||||
|
Digital/Analog 3Coaxial +5P+6C |
28 |
7/0.127 |
8.5 |
Coaxial:7.5 Pair:100 |
200 |
0.18 |
||
30 |
7/0.102 |
7.3 |
400 |
0.35 |
||||
|
Analog 3Coaxial +1P+6C |
28 |
7/0.127 |
8 |
600 |
0.45 |
|||
30 |
7/0.102 |
7 |
800 |
0.55 |
||||
Why choose us?
Customers logo: Acceptable
Changing on material:color, shape, construction; Acceptable
100% inspection before packing
Third party inspection: Acceptable
Quality Control:
All products must go through double checks before manufacturing process
Relevant material check before production
Full check after every individual process finished
Full check after production half-done
Spots check after production packed before shipping
Guarantee:
Customer’s interests can be full guaranteed
Every defective product or quality problem(besides the damage during transportation can be replace in the next order)
Any defective product or quality problem which cause customer’s losses can be compensated in their next order.
Packaging&Shipping
The shipping ways and packaging are up to the customer!
Founded in 2001, after 10 years of unremitting efforts,Ningbo Broad Electronics Co.,Ltd.has developed into a research and development, design and production of various electronic and communication equipment and so on various aspects of the leading professional manufacturer, our main products include: HIGH SPEED (with Ethernet) HDMI cable and conversion, USB line and mobile phone cable, jumper, network lines, lines to DP, VGA line, SATA, audio and video lines and related communications equipment spare parts
The company has passed ISO9001:2000 quality management system and ISO14001:2004 environmental management system certification.All products meet the ROHS standard, some products also has obtained the UL and CE certification, starting in 2007, bo lu DE is HIGH SPEED (with Ethernet) HDMII association members, all of the HIGH SPEED (with Ethernet) HDMII products comply with REACH standard.To 2014, and become a stable supplier of SONY, LG, SAMSUNG, including production of mobile phone cable in LG, SAMSUNG global purchase quantity is much.
