Ceramic Ball Bearing 689RS

Ceramic Ball Bearing 689RS thumbnail-1
Ceramic Ball Bearing 689RS photo-1
US$ 0.15 - 12.75 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Brand Name:
KMY/OEM
Bore Size:
90,
Outside Diameter:
160,
Contact Supplier Request Quote Chat Now
Jinan Kaiming Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao/shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name KMY/OEM
Bore Size 90,
Outside Diameter 160,
Model Number 689
Precision Rating p6
Seals Type RS
Number of Row Single Row
Place of Origin China

Specifications

Ceramic ball bearing 689RS
1.Certificate:ISO9001:2000
2.Material:GCR-15 chrom steel.
3.OEM service.
petitive

China high quality bearing 689rs

1.Drawing of bearing 689rs:

1)Size:20*47*14mm

2)Certificate:ISO9001:2000
3)Material:GCR-15 chrom steel,Bearing Steel
4)OEM service



2.Deep groove ball bearing list:

689rs detail

Bearing No. Boundary dimensions Basic load ratings (kN) Limiting speed Mass
mm Dynamic Static rpm Kg
d D B rs min Cr Cor Grease Oil
6200zz 10 30 9 0.6 5.1 2.38 25000 30000 0.032
6201z 12 32 10 0.6 6.82 3.05 22000 26000 0.035
6202-2z 15 35 11 0.6 7.65 3.72 19000 23000 0.045
6203 2rs 17 40 12 0.6 9.58 4.78 18000 21000 0.064
6204 2rs1 20 47 14 1 12.8 6.65 16000 18000 0.103
6205-2rs 25 52 15 1 14 7.88 13000 15000 0.127
6206zz 30 62 16 1 19.5 11.5 11000 13000 0.2
6207-2z 35 72 17 1.1 25.5 15.2 9800 11000 0.288
6208zz 40 80 18 1.1 29.5 18 8700 10000 0.368
6209zz 45 85 19 1.1 31.5 20.5 7800 9200 0.416
6210zz 50 90 20 1.1 35 23.2 7100 8300 0.463
6211 2rs 55 100 21 1.5 43.4 29.4 6400 7600 0.607
6212 2rs1 60 110 22 1.5 52.4 36.2 6000 7000 0.783
6213 2z 65 120 23 1.5 57.2 40.1 5500 6500 0.99
6214 2z 70 125 24 1.5 62.2 44.1 5100 6000 1.07
6215 2z 75 130 25 1.5 67.4 48.3 4800 5600 1.18
6216 2rs1 80 140 26 2 72.7 53 4500 5300 1.4
6217 2rs1 85 150 28 2 84 61.9 4200 5000 1.79
6218 2rs1 90 160 30 2 96.1 71.5 4000 4700 2.15
6219 2rs1 95 170 32 2.1 109 81.9 3700 4400 2.62
6220 2z 100 180 34 2.1 122 93.1 3500 4200 3.14
6221 2z 105 190 36 2.1 133 105 3400 4000 3.7
6222  c3 110 200 38 2.1 144 117 3200 3800 4.36
6224 120 215 40 2.1 155 131 2900 3400 5.15
6226 130 230 40 3 167 146 2700 3100 5.82
6228 140 250 42 3 166 150 2500 2900 7.57
6230 150 270 45 3 176 168 2300 2700 9.41
6232 160 290 48 3 185 186 2100 2500 11.7
6234 170 310 52 4 212 223 2000 2400 14.5
6236 180 320 52 4 227 241 1900 2200 15.1
6238 190 340 55 4 255 281 1800 2100 18.2
6240 200 360 58 4 269 310 1700 2000 21.6
6244 220 400 65 4 297 365 1500 1800 30



3.Application of bearing 689rs:

Deep groove ball bearing 689rs can be used in transmission, instrumentation , electrical , household appliances, internal combustion engines,

 transport vehicles , agricultural machinery, construction machinery , engineering machinery , roller skate style , yo-yo , etc.



 4.Some pictures of bearing 689rs

Product name

Ball Bearing 689rs

Brand name

 KMY/OEM

Original Packing

(a)Neutral package & wooden package
(b)Carton /Wooden package+pallet(fumigation-free)
(c)As customer request

Precision

P2/P4/P5/P6/P0

Quality standard

ISO9001:2000

Delivery date

Within 5 working days or according to you request

Payment terms

A:100% T/T in advance at sight

B:30%T/T in advance.70% against copy of B/L
C:Western Union

Bearting Application

Sugar mill;Plastic machinery;Papermaking machinery;Oil industry;Instrument;

Steel industry Automobiles;Air blower;Rolling mill;Home application;and so on.

Features

these bearings are featured by the extremely big axial load carrying capacity and

meanwhile,they can also carry cetain radial load

Package

sigle box/industrial standard packing/single carton/according to   buyers requirement

Cage Material

Bearing steel/brass

Main market

Mideast;Canda;Southeast Asia;South America and other countries all over the world

Company name

Jinan Kaiming Bearing CO.,LTD

Contact

Helen Gao

Skype:qgbearing2013

Tel:0086-0531-85066228

Fax:0086-0531-85066708

 ceramic ball bearing 689RS

ceramic ball bearing 689RS

5.Our company can supply all the types of bearing

Main Bearing types:

1)Spherical roller bearing; (21000,22000,23000,24000,29000 Series)

2) Tapered roller bearing; (30000 series and Inch Size.)

3) Thrust ball Bearings. (50000series)

4) Pillow Block ball bearing (UCP, UCF, UCFL)

5) low-noise deep groove ball bearing (mostly 6000 series)

6)angular contact ball bearing;

7)self-aligning ball bearing;

8)cylindrical roller bearing;

9)thrust roller bearing
